PR & PS |SERIES




         2/3 WAY HYDRAULIC PULLERS                                                           WWW.DURAPAC.COM




   F                                                           thE pr & pS-SerIeS puLLErs arE a

                                                               coNvErtibLE 2 or 3 way uNit for a oNE
                                                               pErsoN opEratioN.
      HYDRAULIC TOOLS             SOCkET hANDLE                capacity. The PS-Series 3 in 1 puller is a double acting unit
                                                               Available in remote and self-contained versions from 4-30 ton

                                                               designed for pushing, outer pulling and inner pulling.
                                    360° ROTATING


                                        on PS-Series

                                TWO SPEED PUMP
                                  on PS-20S & PS-30S
                                                          360° ROTATING ON A 90°
                                                                       COUPLING
                                                                                              E
                                                                       on PR-Series
                                                                                                      H
                                                                                                  F



                                                                         2/3 WAY            RANGE OF SPREAD
                                                                   convertible jaw set
                                                                                            C
                                                                LOCkING COLLAR
                                                               for fast easy jaw locking

                                                                EXTENSION RODS        B    A
                                                                  on 4-12 ton models                     G
                                                                 SPRING LOADED
                                                                       centring point
                                                                                        MAX.
                                                                    PULLER LEGS         REACH
                                                             are drop forged for strength
                                                                     CARRY CASE
                                                                           included



                                                 Range of   Extension Rods  Jaw Tip (mm)  Hydraulic Cylinder   Stroke
                                 Capacity  Max. Reach                                   (mm)       (mm)   Weight
          Model No.   Puller Type                 Spread
                                   (ton)  (mm)                                                             (kg)
                                                   (mm)   58 mm - Qty  A   B    C    E    F   G      H
          PS-04S     Self-contained        190   67.5 - 325   2       13   10  22   42   22   40    60      8
                                    4
          PR-04        Remote              190   67.5 - 325   2       13   10  22   42   22   40    60      6
          PS-08S     Self-contained        280  107.0 - 450   3       13   13  27.5  50  25   70    85      12
                                    8
          PR-08        Remote              280  107.0 - 450   3       13   13  27.5  50  25   70    85      9
          PS-12S     Self-contained        305   94.5 - 485   4       15  16.5  29  60   28   70    85      15
                                   12
          PR-12        Remote              305   94.5 - 485   4       15  16.5  29  60   28   70    85      12
          PS-20S     Self-contained        365  128.4 - 570   -       20   27  33   80   40   62    111     26
                                   20
          PR-20        Remote              365  128.4 - 570   -       20   27  33   80   40   62    111     24
          PS-30S     Self-contained        465  128.5 - 680   -       20   27  38   98   50   85    111     36
                                   30
          PR-30        Remote              465  128.5 - 680   -       20   27  38   98   50   85    111     34
