DHS |SERIES




         WWW.DURAPAC.COM                                                                        REMOTE SPREADERS




                                                                                                                    e






          DhS-15 ADvANTAGES
          •  designed for rugged
           operating applications
          • 15 ton spreading force                                                                                    BOLTING SOLUTIONS
          •  5-15 mm spreading capability
          • serrated jaws for grip
                                                                                      CAPACITY
                                                                                      0.5 - 15 ton

                                                                                      SPREAD
                                                                                      2.3 - 99 mm
                                                                                      MAXIMUM OPERATING
                                                                                      PRESSURE
                                                                                      700 bar



             DhS-15
                                     STROKE
                                       25
                                                3/8"-NPTF
                                                                     5
         45 31                        Ø36             Ø48  Ø63  51 41 15

                                                                            23°
                                                                                       232





          DhS-1 ADvANTAGES
          •  1 ton spreading force
          •  12-99 mm spreading capability
          •  general purpose spreader for
           many industrial applications




















              DhS-1                                                                                3/8"-NPTF
                                                                99 89
                                                                                                              56
            55
                                                                    11.2
                                                                                     231
