DHS |SERIES




         REMOTE SPREADERS                                                                    WWW.DURAPAC.COM




   e                                                           thE DHS-SerIeS of rEmotE hyDrauLic

                                                               sprEaDErs arE iDEaLLy suitED to sprEaDiNG,
                                                               LiftiNG aND LEvELLiNG worKs.
      BOLTING SOLUTIONS                                        All models feature high strength steel construction and spring
                                                               The DHS-5 model is designed for flange spreading operations.

                                                               return cylinder.











                                                                                     3/8"-NPTF
              DhS-5
          DhS-5 ADvANTAGES

          • 5 ton spreading force
          •  2.3-76 mm spreading
           capability                                                330
          • jaws open parallel
          •  will not drift away
           or creep down
          • all metal construction                                                              38 L x 114 W

                                                                                                      MIN. 2.3
                                                                                                      MAX. 76












          DhS-05 ADvANTAGES
          •  1/2 ton spreading force
          •  13-90 mm spreading capability
          •  economy model



                                                                                                         DhS-05

                                                                                      193
                                                                                                      3/8"-NPTF


                                                                     48
           Model   Capacity  Oil Capacity   Tip Clearance   Spread    Weight
          Number   (ton)   (cc)   Min. (mm)  Max. (mm)  (kg)
          DHS-05   0.5      9.5     13.0      90     1.9            90
          DHS-1    1.0     14.0     12.0      99     2.2
          DHS-5    5.0     82.0      2.3      76     6.2           60
                                                                        13
          DHS-15  15.0     26.0      5.0      15     3.5
