HC |SERIES




         REMOTE & SELF CONTAINED HYDRAULIC CUTTERS                                           WWW.DURAPAC.COM




   F                                                           thE Hc-SerIeS of rEmotE aND sELf-

                                                               coNtaiNED hyDrauLic cuttErs coNsists of
                                                               six moDELs with a cuttiNG capacity up to
      HYDRAULIC TOOLS  hC-85S                                  They cut with ease through cable, round bar, wire rope, wire
                                                               120 mm DiamEtEr.


                                                               strand and more. They are a proven performer in the electrical,
                                                               railway, mining, manufacturing and construction industries. The
                                                               HC Series Cutters feature superior guillotine-type cutting, flip-
                                                               top latch for easy insertion of cutting material and blades that
                                                               are easily replaceable. The two larger self-contained models
                                                               incorporate a two stage pump. All models are spring return
          135
                                                               and the self-contained models have a 180° rotating head. The
                                                               remote models can be operated by a 700 bar single acting
                                                               hydraulic pump or power unit. They are compact, lightweight,
                                    670                        easy to use and are supplied in a heavy duty canvas carry bag.


           58











                    hC-85R                                           hC-55R






          135
                                                                                                            209



                                    440
                                                                                    425



           58                                                                                               92




                                         Wire Rope                                                                                        Guy Wire
                                                         Soft Steel Bar   Reinforcing   Copper Cable   Aluminium                                                        Max. Pressure                          Cylinder Stroke
           Model No.   Operation                                                                       ACSR (mm)                                           CCP Cable (mm)           Oil Required (cc) Max. Output (ton)      Weight (kg)
                                    6x7    6x12   6x19      (mm)     Rod (mm)     (mm)     Cable (mm)                                                                      (bar)                                  (mm)
                                   (mm)    (mm)   (mm)                                                                             1x7 (mm)     1x19 (mm)
          HC-24S      Self-contained  18    24     24       20          16         24         24          24                          16          16            -           700          56           6.7         28.0          4.0
          HC-45S      Self-contained  22    25     25       20          16         45         45          45                          16          20            -           700          145         10.0         50.0          7.0

          HC-55R        Remote      25      30     30       22          19         50         50          50                          16          20            -           700          106         14.9         55.6          9.0

          HC-85R        Remote       -      -       -        -          -          85         85          -                           -            -           85           700          73           5.6         90.8          5.1
          HC-85S      Self-contained  -     -       -        -          -          85         85          -                           -            -           85           700          168          5.6         90.8          9.0
          HC-120R       Remote       -      -       -        -          -          120        120         -                           -            -           120          700          193         10.6        129.6         10.0


         124
