BS |SERIES




         WWW.DURAPAC.COM                                                               CROSS BEARING ATTACHMENTS




                                                                                                                    F
         thE BS-SerIeS cross bEariNG attachmENts
         proviDE a KNifE-LiKE EDGE to GEt bEhiND
         parts for aDDED vErsatiLity aND sEcurE
         rEmovaL of parts.
         Great for parts that do not offer adequate grip with jaw type
         pullers. All bearing/pulley attachments include the bearing
         attachment, a pair of sized thread-in legs and a sliding cross                                               HYDRAULIC TOOLS
         head. Simply add the hydraulic cylinder from your PR/PS-
         Series puller set.


                                                                                      CAPACITY
                                                                                      4 - 30 ton

                                                                                      SPREAD RANGE
                                                                                      5 - 495 mm






























                                                                              BEARING/PULLEY ATTAChMENT SET
                     J


                  K

                                                 I
                                                                            L
                 A-A
               SECTION             G

                                                                                M                   N
                                  H


                     G     H    I     J         K    Weight
          Model No.                                                                    Spread
                  (Min./Max.) (mm) (mm)               (kg)               Capacity   Reach      Weight    Inc. Bearing
                                                                *Model No.
          BS-5-60   5-60  125  70  3/8”-24UNF 3/8”-16UNC  0.6             (ton)   L    M   N    (kg)   Attachment
          BS-15-60  15-60  135  127 1/2”-20UNF 3/8”-16UNC  1.4                  (mm) (mm) (mm)
                                                                BS-04250   4     250  110  55   6.5    BS-12-70
          BS-12-70  12-70  163  156 5/8”-18UNF 1/2”-12UNC  2.5
          BS-28-150  28-150  260  204 3/4”-16UNF 5/8”-11UNC  5.5  BS-08270  8    270  220  95   9.5    BS-28-150
          BS-20-200  20-200  350  288  1”-14UN  3/4”-10UNC  8.5  BS-12380  12    380  290  225   13    BS-20-200
                                                                * Excludes cylinder pump
