CUTTER – CHAMFER &
INSULATION

CABLE PREPARATION TOOLS (MADE IN ITALY)

MODEL No. 17240 CHAMFER CUTTER

To make chamfer cuts of the primary insulation, of medium-voltage-
cables having primary insulation diameters of 15-60mm.

• Anodised Aluminium construction provides an extremely light
and robust tool
• For chamfering the primary insulation (2 chamfers of 60°)
• The clamping system locks the tool precisely on the cable
• Silicone Gel is not required
I CABLE PREPARATION
• Replaceable hardened steel blade
• Rotation diameter 220mm maximum

Dimensions Weight
Model No. Description (mm) (kg)
1724 0 UFS Cutter with Case 170x50x90 0.39
Above Kit Contents (Components not sold separately)
1724 1 Cutter Only - 0.37
Spares
1724 2 Replacement Blade - -
1710 0 Hollow Hex Wrench 2.5mm - -

MODEL No. 17230 INTERNAL INSULATION CUTTING TOOL

For removal of the primary insulation up to 15mm insulation
thickness on medium voltage cables (6-45kV) with diameters
from 15-52mm.

• Anodised Aluminium construction provides an extremely light and
www.specialisedforce.com.au
robust tool
• Contact surfaces are coated to provide low frictional resistance
• The clamping system locks the tool precisely on the cable
• For removal of insulation at terminations
• Spiral or straight cut possible
• Forward feed can be adjusted in 5 steps
• Cutting depth selectable 0-15 mm
• Any required length of insulation can be removed. Insulation
removal can be terminated at any selected point
• Replaceable hardened steel blade
• Rotation diameter max 220 mm

Dimensions Weight
Model No. Description
(mm) (kg)
1723 0 IMS II Complete Set 275x220x65 1.00
Above Kit Contents (Components not sold separately)
1723 1 Cutter Only - -
AG1013 Silicone Gel - -
1710 0 Hollow Hex Wrench 2.5mm - - SCAN
128940 Plastic Case with Foam Insert - - & PLAY
Spares
1723 2 Replacement Blade - -
