STRIPPER – OUTER SHEATH

AMS SERIES UNIVERSAL CABLE STRIPPERS
(MADE IN ITALY)

FEATURES

For stripping the outer sheath from all MV and LV
cables. Suitable for work on live parts up to 1000V AC
and 1500V DC (model AMS 1000V).
Designed to strip up to 5mm thick outer sheaths from all
MV and LV cables with minimum 25mm outside diameters
(limitation only for circular cuts). Suitable for work on live parts
up to 1000V AC and 1500V DC (Model AMS 1000V - Model No.
17130 only).
• Longitudinal and circular cuts
• Designed to strip both ends and in the middle
• Depth adjustment from 0 to 5mm SCAN
• Stripping without damaging conductor or screen & PLAY
• Interchangeable two-sided blade
• Easy stripping down to -10°C
• Snap closure mechanism (AMS only) I CABLE PREPARATION
• Model AMS 1000V is also designed for very low temperature
uses, down to -40°C

Applications

LV cable with PVC insulation

MV cables with polyethylene insulation

MV cables with PVC outer insulation

Telecommunications cables


www.specialisedforce.com.au

Model No. AV6220 17130 AV6299
Details AMS AMS 1000V Insulated AMS Replacement Blade
Supplied With Sturdy case to contain the tool and its
instructions for use
Weight (kg) 0.2 0.2 0.1
Dimensions (mm) 160x35x65 170x50x75 N/A
