Page 333 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

STRIPPER – SEMI-CONDUCTOR

CABLE PREPARATION TOOLS (MADE IN ITALY)

MODEL No. 1722 1 SEMI-CONDUCTOR SCREEN REMOVAL
TOOL

For removal of the vulcanised semi-conducting screen up to 1.5mm
thick on medium and high voltage cables with thicknesses of
insulation in the range 10-52mm.

• Anodised Aluminium construction provides an extremely light and robust
tool
• Contact surfaces are coated to provide low frictional resistance
• The change over lever allows activation/de-activation of axial movement
• Removal of the screen can start or stop at any point required
• Axial movement in both directions possible
• The shape of the blade ensures that the end of the screen layer will always
be conical
• Blade of tempered steel
• Cutting depth using special blade with stripping depth with cone from 0 till
1,5 mm adjustable I CABLE PREPARATION
• Cutting depth can be limited or blocked
• Very small rotation of 220mm OD max.
• Shaved screen deflected away using the guiding device on the tool

Model No. Description Dimensions (mm) Weight (kg)
1722 0 FBS Complete Set 235x200x55 0.80
Above Kit Contents (Components Not Sold Separately)
1722 1 Stripper Only - - SCAN
AG1013 Silicone Gel - - & PLAY
1710 0 Hollow Hex Wrench 2.5mm - -
128930 Plastic Case - -
Spares
1714 2 Replaceable Blade - -

MODEL NO. HLS NON-VULCANIZED SEMI-CONDUCTIVE CABLE STRIPPER

Designed to strip the non-vulcanized semi-conductive
layer of MV cables - 16-41mm OD.
• Longitudinal, helical & circular cuts
• Positioned on the cable like a vice system
• Stop clamp to limit the stripping length
• Step-by-step depth adjustment from 0-0.9mm www.specialisedforce.com.au
• Cutting depth can be increased to 2mm by moving reference 0
• Easy stripping down to -10°C

Model No. AV6400
Weight (kg) 0.6
Dimensions (mm) 250 x 160 x 55
Kit Inclusions
HLS - AV6410 Cable Application Range (mm OD) 16 – 41
Stop Clamp – AV6411 Insulation Thickness (mm) 0 – 2
Tube of Silicone Grease – AG1013
Rigid Case Max. Rotating Diameter (mm) 130
