P. 328
CONDUCTOR TRIMMER –
FOR ACSR
MODEL No. PSC-1 ACSR TRIMMER (MADE IN USA)
FEATURES
The PSC-1 ACSR Trimmer quickly and accurately removes the aluminium stranding from around the
steel core of ACSR conductors. Made of an aluminium alloy, this tool is lightweight and durable. The
cutter, bushing holder and case are sold as one unit.
The case has slots to store 10 bushings while the 11th bushing can be stored in the tool.
• Bushes are fully interchangeable with rigid #87 ACSR Trimmer Bushes.
• Weight: 4.3kg
STANDARD BUSHINGS
I CABLE PREPARATION
Model No. Conductor Name OD in mm
87CHERRY CHERRY 14.30
87GRAPE GRAPE 17.50
87PANTHER PANTHER 21.00
87LEMON LEMON 21.00
87LYCHEE LYCHEE 22.80
87BEAR BEAR 23.45
87LIME LIME 24.50
87MANGO MANGO 27.00
87ZEBRA ZEBRA 28.62
87ORANGE ORANGE 29.30
87OLIVE OLIVE 31.50
NOTE
• Other size bushes can to suit the PSC-1 ACSR Trimmer can be manufactured to order.
• Replacement Cutter Wheel: Model No. 54270.
• Full range of spare parts to suit PSC-1 are available on request
