LINE TROLLEY & BICYCLE

LINE TROLLEY – SINGLE PERSON, SINGLE CONDUCTOR

F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
Model No. C150.11
Single-seat line car fit for single-conductor lines. Aluminium
Description alloy structure with nylon wheels mounted on ball-bearings.
Parking brake. Nylon band for back support. Foot rest.
Capacity (KG) 100
Weight (KG) 6.5

LINE TROLLEY – 1 – 2 PERSONS, SINGLE CONDUCTOR (MADE IN ITALY)

Model Series C 155.10
Fit for 2 people. Manual pull type.
Aluminium alloy structure with
nylon wheels mounted on ball-
bearings. Parking brake. Equipped
with metre counter.

Model Series C 155.11
Fit for 2 people. Manual pull type.
Aluminium alloy structure with
nylon wheels mounted on ball-
bearings. Parking brake. Equipped
with metre counter.

Model No. Suitable for Capacity (kg) Length (mm) Height (mm) Width (mm) Weight (kg)
Persons
C 155.10.A 1 100 650 1650 630 28
www.specialisedforce.com.au
C 155.10.B 2 200 1000 1650 630 28
C 155.11 2 200 2820 2150 610 82
CONDUCTOR BICYCLE (MADE IN ITALY)

DETAILS

Cable or conductor bicycles for single, twin, three and four bundle
conductor. Nylon wheels are mounted on ball-bearings.

The conductor bicycle is suitable for travelling along conductors similar to that of
a common bicycle. Units are equipped with negative-type disc brake and a safety
brake clamping the conductor, transmission by cardanic joint, safety belt, and
metre counter.
Optional: Bag for conductor spacers – available upon request.

Conductor Type Model No. Capacity (kN) Dimensions (m) Weight (kg)

C 175.1 1 1.15x0.50x1.81 26

C 175.2 1 0.75x0.70x1.40 34

C 175.3 1 0.70x0.60x1.40 40

C 175.4 1 1.60x0.70x1.50 49
