GROUNDING DEVICE &
EARTH STAKE

MODEL No. C 35 PORTABLE STRINGING EARTH
(MADE IN ITALY)

Grounding device to be used while stringing overhead conductors or pulling
ropes. Aluminium alloy sheaves with bushes grant a good sliding and electric continuity even on junction points.
Contrast spring for a safe and continuous contact on conductors with junction clamp. Supplied with:
• Copper cable section 50 mm² lined with high-insulating protection, length 6 m.
• Brass clamp, clamping capacity 0 - 40 mm.
• Metallic box for storage (mod. C35.2 and C35.1).
• Plastic box for storage. F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT

OPTIONS
01 Steel-wheels fit for anti-twisting steel rope (only for C35.2).

Fit for Dimensions Weight Metallic Box Metallic Box
Model No. Short Circuit Conductor Ø Dimensions Weight
Current
(mm) (mm) (kg) (mm) (kg)
C35.1 10kA/0.4sec 3-40 500 x 420 x 180 x 85 17.0 600x600x250 17.0
C35.2 10kA/0.4sec 10-60 430 x 370 x 150 x 65 6.5 500x500x200 14.0

MODEL No. TES 770 TEMPORARY EARTH STAKE

Provides a ground where a system ground is not available. With “slide hammer” action to
drive in and out, this item can be re-used. Marked at 600mm for good earth connection. Australian Made www.specialisedforce.com.au
Also has tab connection for bolted earth lead. Reduces the risks off manual handling using
the old method of hammering in a steel peg.

Chisel tip

Tab for lead connection
