SUSPENSION PLATFORMS

F 127 SERIES SUSPENSION PLATFORMS (MADE IN ITALY)

Suspension platform for overhead line works. Aluminium alloy structure. Made
F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
of two or more trapezoidal sections, with central fitting and lateral hooks for
anchoring. Complete with wire ropes and turnbuckles.
SPECIFICATIONS

P
P1 P1

A
L1 L1
L C
B
P
P1 P1
701 & 703

L1 L1 L1

L

P
P1 P1

L1 L1 L1 L1
L

www.specialisedforce.com.au
OPTIONAL
701 – Trolley for hydraulic press, swivelling 360°.
703 – Rail for press-trolley
704 – Double-side anti-fall protection
704.1 – Single-side anti-fall protection
Custom built suspension platforms with higher capacities or different lengths made to order
Total Length Length of Each Section Part WLL P1 Total WLL P1&P1-(P) Dimensions (mm)
Model No. UTS (kg) Wt (kg)*
(m) L1 (m) (kg) (kg) A B C
F 127.4 4 4 300 600 1800 350 90 400 50
F 127.5 5 5 300 600 1800 350 90 400 59
F 127.6(²) 6 6 300 600 1800 350 90 400 64
F 127.6.2 6 3+3 300 600 1800 350 90 400 69
F 127.8.2 8 4+4 300 600 1800 350 90 450 85
F 127.12.2(²) 12 6+6 300 600 1800 350 90 450 115
F 127.14.3 14 5+4+5 300 600 1800 350 90 450 130
F 127.16.3(²) 16 5+6+5 300 600 1800 350 90 450 140
F 127.18.3 18 6+6+6 300 600 1800 350 90 450 164
F 127.20.4(²) 20 5+5+5+5 300 600 1800 450 90 550 198
(*) Weight Including 1 Single Antifall Device Opt.704.1
