LINE TROLLEY – 1 – 2 PERSONS,
MANUAL & MOTOR

C 155.C SERIES (MANUAL) (MADE IN ITALY)

Line-car suitable for 2 people fit for 2, 3 or 4 bundle conductor.
Light aluminium-alloy structure welded TIG-system. Four opening arms for
wheels, fit for passing obstacles. Aluminium wheels mounted on bearings.
Parking brake. Metre counter. Service platform. Fit for 2 operators.

OPTIONAL
• Nylon wheels mounted on
bearings
• Negative disk brake, with
manual opening
• Arms for wheels openable
with horizontal rotation F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT

Max. Dimensions (mm) Weight
Model No. Conductors Load
(kg) A A1 B B1 C C1 D E (kg)
C155.C.2 2 250 2070 1900 1270 950 1570 1390 865 400-500-600 87
C155.C.3 3 250 2070 1900 1270 950 1570 1390 865 400-500-600 90
C155.C.4 4 250 2070 1900 1270 950 1570 1390 865 400-500-600 92

C155.CM SERIES (MOTORISED)

Motorised line-car for 2 people fit for 2-, 3- or 4- bundle conductor.
Light aluminium-alloy structure welded TIG-system. Four openable arms for wheels, fit for passing obstacles.
Aluminium wheels lined with high grip rubber. Parking brake acting on the conductor. Metre counter. Service
platform. Fit for 2 operators. Hydraulically driven wheels. Petrol engine 2.9 kW. Variable speed 0 to 30 metres/
min in both directions. Maximum inclination allowed: 40%. Power pack is removable.

OPTIONAL
• Arms for wheels openable
with horizontal rotation
• Earthing Device
• N.2 disk brakes manually
operated by 1 lever
• N.4 disk brakes manually
operated by 2 levers
• Special structure with load
capacity = 400kg
NOTE: The weight is 20% higher than the standard version www.specialisedforce.com.au

Max. Dimensions (mm) Weight
Model No. Conductors Load
(kg) A A1 B B1 C C1 D E (kg)
C155.CM.2 2 250 2070 1900 1270 950 1570 1390 865 400-500-600 188
C155.CM.3 3 250 2070 1900 1270 950 1570 1390 865 400-500-600 197
C155.CM.4 4 250 2070 1900 1270 950 1570 1390 865 400-500-600 205
