Page 254 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

LADDERS – SUSPENSION/
PLATFORM

C 167F SERIES SUSPENSION LADDER/PLATFORM
(MADE IN ITALY)
F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
MODEL No. C167F

Suspension ladder fit for vertical or horizontal use. F
Aluminum alloy structure welded with TIG system, complete
with T profile for anti-fall device. Interchangeable tower
hook made of galvanized steel. The foldable end with
conductor hook allows the ladder to be used as a horizontal DA1 - SUPPLIED
platform. Also available versione C167.G...S, working load WITHOUT LANYARD A
200 daN.
OPTIONAL
G = 220 mm F = 100 mm
01 - Conductor hook complete with nylon sheave. B = 1000 mm A = 900 mm
DA1 - Anti-fall device. G L

SPECIFICATIONS
Model No. (AS) Total Length No of Vertical WLL Horizontal WLL
Single Guide (m) (L) Sections (kg) (kg) Wt (kg)
C 167.F.301 3.0 1 300 100 16.5
C 167.F.401 4.0 1 300 100 20.0
C 167.F.601 6.0 1 300 100 29.5

C167G SERIES SUSPENSION LADDER/PLATFORM

Suspension ladder fit for vertical and
horizontal use. Aluminum alloy structure
welded with TIG system, complete with T F
profile for anti-fall device. The two foldable
www.specialisedforce.com.au
ends, fitted with hooks for tower and for G
conductor, allows the ladder to be used as
a horizontal platform. Also available version B A
C167.G...S, working load 200 daN.

OPTIONAL
01 - Conductor hook complete with nylon G = 220 mm F = 100 mm
L
sheave. B = 1000 mm A = 900 mm
G = 220 mm F = 100 mm
DA1 - Antifall device.
B = 1000 mm A = 900 mm
SPECIFICATIONS
Model No. (AS) Total Length (m) Horizontal WLL
Single Guide (L) No of Sections Vertical WLL (kg) (kg) Wt (kg)
C 167.G.301 3.1 1 300 100 18.5
C 167.G.401 4.1 1 300 100 22.0
C 167.G.601 6.2 1 300 100 32.0
