WIRE GRIPS

WIRE GRIPS (MADE IN JAPAN)

F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
SPECIFICATION
AL-LARGE-30-GRIP

For Bare ACSR, AL & Copper Cable

WLL Min. Cable Max. Cable Jaw Length Eye Size
(kN) (mm) (mm) (mm) (mm) Weight (kg)
30 18 35 120 32x42 2.4

LARGE CAPACITY GRIPS
40KN-GRIP
For Messenger Wire, Wire Rope, Trolley Cable, Copper Cable

WLL Min. Cable Max. Cable Jaw Length Eye Size Weight (kg)
(kN) (mm) (mm) (mm) (mm)
40 8 28 140 43x51 3.5

AL-50KN-GRIP

For Bare ACSR, AL-Cable and Bare Copper-Cable Only

WLL Min. Cable Max. Cable Jaw Length Eye Size Weight (kg)
(kN) (mm) (mm) (mm) (mm)
50 18 36 180 43x51 4.7

www.specialisedforce.com.au
AL-60KN-GRIP

For Bare ACSR, AL-Cable and Bare Copper-Cable Only

WLL Min. Cable Max. Cable Jaw Length Eye Size Weight (kg)
(kN) (mm) (mm) (mm) (mm)
60 28 46 220 60x51 7.0

TWIST GRIP FEATURE
