WIRE GRIPS

WIRE GRIPS (MADE IN JAPAN)

SPECIFICATION

20KN-W-GRIP

For Bare Copper Cable, Covered Cable, Trolley Wire, Guy Wire & Wire Rope

WLL Min. Cable Max. Cable Jaw Length Eye Size
(kN) (mm) (mm) (mm) (mm) Weight (kg)
20 5 22 90 32x42 1.5

35KN-GRIP
For Bare Copper Cable, Covered Cable, Contact Wire, Guy Wire & Wire Rope F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT

WLL Min. Cable Max. Cable Jaw Length Eye Size
(kN) (mm) (mm) (mm) (mm) Weight (kg)
35 5 22 90 32x42 1.7

H-35KN-GRIP
For Bare Copper Cable, Covered Cable, Contact Wire,
Guy Wire & Wire Rope

WLL Min. Cable Max. Cable Jaw Length Eye Size Locking Grip Type
(kN) (mm) (mm) (mm) (mm) Weight (kg) Available
35 5 22 90 32x42 1.7 H-35KN-GRIP-LK
MIGHTY-20-GRIP

For Bare Copper Cable, Covered Cable & Guy Wire

WLL Min. Cable Max. Cable Jaw Length Eye Size Weight Locking Grip Type
(kN) (mm) (mm) (mm) (mm) (kg) Available
20 5 28 120 32x42 1.9 MIGHTY-20-GRIP-NS

H-MIGHTY-20-GRIP
For Bare AL, ACSR & Copper Cable

WLL Min. Cable Max. Cable Jaw Length Eye Size Weight Locking Grip Type
(kN) (mm) (mm) (mm) (mm) (kg) Available www.specialisedforce.com.au
35 5 28 120 32x42 1.9 H-MIGHTY-20-GRIP-LK

LOCK OPEN NOTCH LOCKING GRIP
This feature allows the grip to be held in the Optional Locking Type Grip Available on the below models
open position for easy insertion of cable, (Add suffix “-LK” to Model No. E.g. 20KN-GRIP-LK)
available on the below models (Add suffix “-NS” • SD-S-GRIP
to the Model No. example 20KN-GRIP-NS).
• MIGHTy-20-GRIP • 35KN-GRIP
• ABC-M-GRIP • MIGHTy20-GRIP
• ABC-M-GRIP-S • AL-10KN-GRIP
• ABC-L-GRIP • AL-20KN-GRIP
• AL-MIGHTy-GRIP
• ABC-L-GRIP
