DRIVER – POST & ROD

POST AND ROD DRIVERS (MADE IN USA)

C HYDRAULIC TOOLS & ACCESSORIES

Sign Post Driver Ground Rod Driver

• Drives a variety of post sizes from small de-linear posts
up to 89 mm round posts including square, “U” channel, • Lightweight allows easy mounting on top of rods.
breakaway stubs, round, “T” fence, and wood. • Can be used with Open- and Closed-Center hydraulic
• Quick change front head design accommodates adapters for systems.
different types of posts. • Dual guide rods provide excellent control for driving rods
• Dual guide handles for good directional control. straight, and the remote on/off valve makes it easy to
• A deep post opening and smooth operation ensures that the control the depth of the rod.
driver will not jump off of posts. • A deep rod opening and smooth operation ensures that
• Available with integral trigger or remote on/off valve. the driver will not jump off of rods.
• U.S. Patent #6,626,247.
SPECIFICATIONS

Style Sign Post Driver Sign Post Driver Ground Rod Driver Ground Rod Driver
Model No. 11183 11186 11192 11193
Sign post driver Sign post driver Ground Rod Driver Ground Rod Driver
Description w/ integral trigger w/remote on/off valve 16mm Opening 25mm Opening
w/ universal post adaptor w/universal post adaptor
www.specialisedforce.com.au
Hydraulic System Open & Closed Centre Open & Closed Centre Open & Closed Centre Open & Closed Centre
Weight (kg) * 34 34 24 24
Length (mm) 813 813 654 654
Flow Range (lpm) 19-30 19-30 19-30 19-30
Blow Energy (J) 110 110 - -
Blows/min @ 30lpm 1500 1500 1740 1740
Max Input Pressure (bar) 160 160 138 138
On/Off Hose Connection Sizes (11183)
Pressure Hose ½” NPTF ½” NPTF - -
Return Hose ½” NPTF ½” NPTF - -
Valve Connection Port Sizes (11186 & 11192/11193)
On/Off Valve Pressure
Port 9/16-18 SAE O-Ring Boss 9/16-18 SAE O-Ring Boss 9/16-18 SAE O-Ring Boss 9/16-18 SAE O-Ring Boss
On/Off Valve Return Port 3/4-16 SAE O-Ring Boss 3/4-16 SAE O-Ring Boss - -
Hose Length (m) 0.305 0.381 1.78 1.78
* Includes Adaptors & Hoses

Model No. 49532 49534 49533 Contact SF for more Information 40290
Suits 11183/11186 11183/11186 11183/11186 11183 11186 11192/11193 ALL
Round Post
Square Post
Description Universal Post Adaptor 54mm Adaptor 96mm Hose Assembly Hose Assembly Hose Assembly Remote Valve
381mm
178mm
305mm
Adaptor
