TAMPER – POLE

POLE TAMPERS (MADE IN USA)

FEATURES

• Makes quick work of setting poles, asphalt patch, and general construction backfill compacting.
• Only three moving parts for low maintenance.
• Kidney-shaped foot included.
• Hose End Valve - Reversible on/off valve for Open and Closed-Centre hydraulic systems.
• Valve on Tube - Rotate trigger spool for Open and Closed-Centre hydraulic systems.
• Includes flush face couplers “FF”.

SCAN
& PLAY

The Tamp-Safe handle was designed by a professional linesman for the C HYDRAULIC TOOLS & ACCESSORIES
safety of utility workers. Tamp-Safe handles are built with safety in mind.
It puts the operator’s hand in a safe position away from the hydraulic
hoses. Our innovative handle is designed to attach to most hydraulic Kidney Shape
tampers, including Greenlee/Fairmont, Reliable, and Stanley tampers. Foot ideal for
Pole Filling

TS1001 TS2001G
Greenlee Hose Greenlee Valve
End Valve Model on Tube Model

See below table for Tamp-Safe models On Tube Valve Hose End Valve
SPECIFICATIONS

Hose End With
Style Hose End Valve No On/Off valve Hose End Valve Valve on Tube Valve on Tube
Model No. 42198/FF 42202/FF 42199/FF 42201/FF 42200/FF
Length (mm) 1500 1500 2200 1500 1800
Open- and
System 9/16 & 3/4 Closed-Center
Flow Range 15-23 15-23 15-23 15-23 15-23
(lpm)
Operating 69-138 69-138 69-138 69-138 69-138
Pressure (Bar)
Pressure Port 9/16-18 SAE 9/16 M18 JIC 9/16-18 SAE 9/16-18 SAE 9/16-18 SAE
O-Ring
O-Ring
O-Ring
O-Ring
Thread 3/4-16 SAE O-Ring 9/16 M18 JIC 3/4-16 SAE 3/4-16 SAE 3/4-16 SAE www.specialisedforce.com.au
O-Ring
O-Ring
O-Ring
Return Port
thread 9/16 M18 JIC 3/4-16 SAE O-Ring
Std Foot Size 63 x 203 63 x 203 63 x 203 63 x 203 63 x 203
(mm) (Kidney Shape) (Kidney Shape) (Kidney Shape) (Kidney Shape) (Kidney Shape)
Blows per 1,160 1,160 1,160 1,160 1,160
minute @ 19lpm
Width (mm) 102 102 102 102 102
Weight (kg) 10.4 10.4 12.7 9.8 10.4
**Tamp-Safe
Model No. TS1001 TS1001 TS1001 TS2001G TS2001G
Suffix “/FF” means supplied with standard low pressure flush face couplings
**NOTE: Models available for Stanley & Reliable - Please Contact your Nearest Specialised Force Branch & Advise the Tamper Model Number
