CRK |SERIES




         MAINTENANCE AND REPAIR KITS                                                         WWW.DURAPAC.COM




   F              DESCRIPTION       STANDARD   CRK-10D  STANDARD   1     Adj. Body Spoon      6      ZAL1064
                                                                          ZAL1002
                                              DELUXE
                                                      CRK-20D
                                     CRK-10
                                                                                                     Box Clamp
          1 2 3  Adj. Body Spoon    ZAL1003  ZAL1002  ZAL1039
      HYDRAULIC TOOLS  4 5 6 7  Pull Ring x 2  ZAL1040  ZAL1068    2      ZAL1003             7      ZAL1068
             3-1/4" Rubber Flex Head
                                             ZAL1003
             Collar Toe
             Pull Clamp x 2
                                             ZAL1063
             Box Clamp x 2
                                             ZAL1064
             Female Connector x 3
          8
          9

                                                      ZAL1070

             254 mm Ext. Tube
                                                      ZAL1071
          10  127 mm Ext. Tube                        ZAL1069          3-1/4" Rubber Flex Head    Female Connector - 20 ton
             508 mm Ext. Tube
          11  699 mm Ext. Tube                        ZAL1072
          12  127 mm Ext. Tube      ZAL1076  ZAL1076
          13  254 mm Ext. Tube      ZAL1077  ZAL1077
          14  508 mm Ext. Tube      ZAL1078  ZAL1078
          15  635 mm Ext. Tube      ZAL1079  ZAL1079               3      ZAL1039             8-11  ZAL1069/70/71/72
          16  Male Connector x 3                      ZAL1073              Collar Toe            127-699 mm Ext. Tube - 20 ton
          17  Male Connector x 2    ZAL1074  ZAL1074
          18  Female Connector x 2  ZAL1075  ZAL1075
          19  Lock Pin x 1 ( x 2 for CRK10D ) ZAL1101  ZAL1101  ZAL1101
          20  Piston Rod Toe        ZAL1177  ZAL1177
          21  Spreader Toe                   ZAL1178
          22  90° V Base            ZAL1179  ZAL1179
          23  Wedge Head            ZAL1180  ZAL1180               4      ZAL1040            12-15 ZAL1076/77/78/79
          24  Wedge Head                              ZAL1100              Pull Ring             127-635 mm Ext. Tube - 10 ton
          25  Flat Base             ZAL1181  ZAL1181
          26  Serrated Saddle       ZAL1182  ZAL1182
          27  Serrated Saddle                         ZAL1097
          28  Piston Rod Base x 2                     ZAL1098
          29  Vee Head                                ZAL1099
          30  Offset Pull Toe x 2            ZAL1183
                                                                   5      ZAL1063            16      ZAL1073
          31  Clamp End Toe                  ZAL1184
                                                                          Pull Clamp              Male Connector - 20 ton
          32  Collar Toe            ZAL1186  ZAL1186

          33  Clamp Head                     ZAL1189
          34  Chain Pull Plate               ZAL1190
                    Weight ?
          35  3/8" x 5' Chain & Hook x 2     ZAL1386
          36  3-Shelf Service Cart           ZAL1009  ZAL1009
          37  Metal Box             ZAL1405   81.5 kg  76.5 kg
                                     39.5 kg



               !         WarninG



                         When cylinders are used with maintenance set attachments or components, the maximum
                         system pressure must generally be limited to half the rated pressure (350 bar).
