                                                                                   LPC |SERIES


         WWW.DURAPAC.COM                                                                METRIC HEXAGON CASSETTES

                                                                                    i                               e


                                                        Did you know...
                                                        Durapac offer extension
                                                        reaction arms and low
                                                        point reaction paddles to
                                                        suit the LPC2-LPC14 low
                                                        profile hydraulic hexagon
                                                        wrenches.


                                                               METRIC HEXAGON REDUCER BUSHES TABLE                    BOLTING SOLUTIONS


 Bolt   A/F    Max.    Max.    Max.    Max.   Max.    Bolt   A/F                Reducer Insert          Holding
 R   A
 A
 R   A
 R
                  R   A
 R   A
 Diameter    Size    LPC2  (mm) (mm)  Torque    LPC4  (mm) (mm)  Torque   LPC8  (mm) (mm)  Torque    LPC14  (mm) (mm)  Torque    LPC30  (mm) (mm)  Torque    Diameter    Size    Hexagon   Ring
 (mm)  (mm)  (Nm)  (Nm)  (Nm)  (Nm)  (Nm)  (mm)  (mm)     Cassette
                                                                     Model No.  Model No.   Model No.  Model No.
 12  19  LPC2-19  27  16  1,663    12     19
                                                        LPC2-32      MR2-32-27     -           -        MHR2-32
 14  22  LPC2-22  27  14  1,663    14     22            LPC2-36      MR2-36-30  MR2-36-27      -        MHR2-36
 18  27  LPC2-27  27  11  1,929    18     27            LPC2-41      MR2-41-32  MR2-41-30   MR2-41-27   MHR2-41
 20  30  LPC2-30  29  12  2,328    20     30            LPC2-46      MR2-46-36  MR2-46-32   MR2-46-30   MHR2-46
 32  LPC2-32  29  11  2,328               32            LPC4-36      MR4-36-30  MR4-36-27      -        MHR4-36
 22  34  LPC2-34  31  11  2,328  LPC4-34  36  16  2,510  22  34  LPC4-41  MR4-41-32  MR4-41-30  MR4-41-27  MHR4-41
 24  36  LPC2-36  31  10  2,328  LPC4-36  36  15  2,510  24  36  LPC4-46  MR4-46-36  MR4-46-32  MR4-46-30  MHR4-46
 27  41  LPC2-41  34  10  2,328  LPC4-41  39  15  5,021  LPC8-41  46  22  8,128  27  41  LPC4-50  MR4-50-41  MR4-50-36  MR4-50-32  MHR4-50
 30  46  LPC2-46  37  10  2,328  LPC4-46  42  15  5,858  LPC8-46  46  19  10,941  30  46  LPC4-55  MR4-55-46  MR4-55-41  MR4-55-36  MHR4-55
 33  50  LPC2-50  40  11  2,328  LPC4-50  44  15  5,858  LPC8-50  46  17  10,941  LPC14-50  60  31  14,552  33  50  LPC4-60  MR4-60-50  MR4-60-46  MR4-60-41  MHR4-60
 36  55  LPC2-55  43  11  2,328  LPC4-55  46  14  5,858  LPC8-55  50  18  10,941  LPC14-55  60  28  18,521  36  55  LPC4-65  MR4-65-55  MR4-65-50  MR4-65-46  MHR4-65
 39  60  LPC2-60  46  11  2,414  LPC4-60  50  15  5,858  LPC8-60  52  17  10,941  LPC14-60  60  25  18,521  39  60  LPC8-55  MR8-55-46  MR8-55-41  -  MHR8-55
                                                        LPC8-60      MR8-60-50  MR8-60-46      -        MHR8-60
 42  65  LPC4-65  53  15  5,858  LPC8-65  55  17  10,941  LPC14-65  60  22  18,521  42  65
                                                        LPC8-65      MR8-65-55  MR8-65-50   MR8-65-46   MHR8-65
 45  70  LPC4-70  56  15  6,474  LPC8-70  58  17  10,941  LPC14-70  60  19  18,521  45  70
                                                        LPC8-70      MR8-70-60  MR8-70-55   MR8-70-50   MHR8-70
 48  75  LPC4-75  59  15  6,474  LPC8-75  60  17  10,941  LPC14-75  63  19  18,521  48  75
                                                        LPC8-75      MR8-75-65  MR8-75-60   MR8-75-55   MHR8-75
 52  80  LPC4-80  61  15  6,474  LPC8-80  63  16  10,941  LPC14-80  66  19  18,521  52  80  LPC8-80  MR8-80-70  MR8-80-65  MR8-80-60  MHR8-80
 56  85  LPC8-85  66  16  10,941  LPC14-85  69  19  18,521  LPC30-85  78  28  41,882  56  85
                                                        LPC8-85      MR8-85-75  MR8-85-70   MR8-85-65   MHR8-85
 60  90  LPC8-90  69  17  10,941  LPC14-90  72  20  18,521  LPC30-90  78  26  41,882  60  90  LPC8-90  MR8-90-80  MR8-90-75  MR8-90-70  MHR8-90
 64  95  LPC8-95  71  16  10,941  LPC14-95  74  19  18,521  LPC30-95  83  28  41,882  64  95  LPC14-75  MR14-75-65  -  -  MHR14-75
 68  100  LPC8-100  75  17  11,774  LPC14-100 77  19  18,521  LPC30-100 83  25  41,882  68  100  LPC14-80  MR14-80-70  MR14-80-65  -  MHR14-80
 72  105  LPC8-105  78  17  11,774  LPC14-105 80  19  18,521  LPC30-105 89  28  41,882  72  105  LPC14-85  MR14-85-75  MR14-85-70  MR14-85-65  MHR14-85
 76  110  LPC14-110 83  19  18,521  LPC30-110 89  25  41,882  76  110  LPC14-90  MR14-90-80  MR14-90-75  MR14-90-70  MHR14-90
 80  115  LPC14-115 87  20  18,521  LPC30-115 95  28  41,882  80  115  LPC14-95  MR14-95-85  MR14-95-80  MR14-95-75  MHR14-95
 117  LPC14-117 87  19  18,521  LPC30-117 95  27  41,882  117  LPC14-100  MR14-100-90  MR14-100-85  MR14-100-80  MHR14-100
 85  120  LPC30-120 95  25  41,882  85    120           LPC14-105   MR14-105-95  MR14-105-90  MR14-105-85  MHR14-105
 125     LPC30-125 101 29  41,882         125           LPC14-110   MR14-110-100  MR14-110-95  MR14-110-90  MHR14-110
 90  130  LPC30-130 101 26  41,882  90    130           LPC14-115   MR14-115-105  MR14-115-100  MR14-115-95  MHR14-115
                                                        LPC30-90     MR30-90-80    -           -       MHR30-90
 95  135  LPC30-135 104 26  41,882  95    135
                                                        LPC30-95     MR30-95-85  MR30-95-80    -       MHR30-95
 140     LPC30-140 110 29  41,882         140
                                                        LPC30-100   MR30-100-90  MR30-100-85  MR30-100-80  MHR30-100
 100  145  LPC30-145 110 26  41,882  100  145
                                                        LPC30-105   MR30-105-95  MR30-105-90  MR30-105-85  MHR30-105
 105  150  LPC30-150 116 29  41,882  105  150           LPC30-110   MR30-110-100  MR30-110-95  MR30-110-90  MHR30-110
 110  155  LPC30-155 116 26  41,882  110  155           LPC30-115   MR30-115-105  MR30-115-100  MR30-115-95  MHR30-115
 160     LPC30-160 128 36  44,593         160           LPC30-120   MR30-120-110  MR30-120-105  MR30-120-100  MHR30-120
 115  165  LPC30-165 128 33  44,593  115  165           LPC30-130   MR30-130-120  MR30-130-115  MR30-130-110  MHR30-130
 120  170  LPC30-170 128 30  44,593  120  170           LPC30-145   MR30-145-130  MR30-145-120  MR30-145-115  MHR30-145
 175     LPC30-175 128 27  44,593         175           LPC30-155   MR30-155-145  MR30-155-130  MR30-155-120  MHR30-155
                                                        Not all imperial reducer bushes are listed, for other sizes contact Durapac
