LPC |SERIES




         METRIC HEXAGON CASSETTES                                                            WWW.DURAPAC.COM




   e                                                                        The LPC wrench head
                                                                            can  be used  with  multiple
                                                                            ratchet cassettes. Reducer
                                                                            bushes are also available.
      BOLTING SOLUTIONS             R       METRIC HEXAGON CASSETTE TABLE




                                              A






                                                                                      Max.
                    A/F
                                           Max.
                                                                 Max.
            Bolt
                                                                                                                                                 Max.
                                                                                                           Max.
                                                                                                                                                                 A/F
                                                                                                                                                         Bolt
                                  R
                                      A
                                                                               R   A
                                                                                                    R   A
                                                                                                                                         R   A
                                                          R   A
                    Size
                                                                                                                                                                 Size
                           LPC2
          Diameter
                                                                                                           (Nm)
                                                                                                                                                 (Nm)
                                                                 (Nm)
                                                                                      (Nm)
                                           (Nm)
           (mm)
                                                                                                                                                         (mm)
                                           1,663
                                  27
                                      16
                    19
                                                                                                                                                          12
                                                                                                                                                                  19
            12     (mm)   LPC2-19  (mm) (mm)  Torque    LPC4  (mm) (mm)  Torque   LPC8  (mm) (mm)  Torque    LPC14  (mm) (mm)  Torque    LPC30  (mm) (mm)  Torque    Diameter    (mm)
            14      22    LPC2-22  27  14  1,663                                                                                                          14      22
            18      27    LPC2-27  27  11  1,929                                                                                                          18      27
            20      30    LPC2-30  29  12  2,328                                                                                                          20      30
                    32    LPC2-32  29  11  2,328                                                                                                                  32
            22      34    LPC2-34  31  11  2,328  LPC4-34  36  16  2,510                                                                                  22      34
            24      36    LPC2-36  31  10  2,328  LPC4-36  36  15  2,510                                                                                  24      36
            27      41    LPC2-41  34  10  2,328  LPC4-41  39  15  5,021  LPC8-41  46  22  8,128                                                          27      41
            30      46    LPC2-46  37  10  2,328  LPC4-46  42  15  5,858  LPC8-46  46  19  10,941                                                         30      46
            33      50    LPC2-50  40  11  2,328  LPC4-50  44  15  5,858  LPC8-50  46  17  10,941  LPC14-50  60  31  14,552                               33      50
            36      55    LPC2-55  43  11  2,328  LPC4-55  46  14  5,858  LPC8-55  50  18  10,941  LPC14-55  60  28  18,521                               36      55
            39      60    LPC2-60  46  11  2,414  LPC4-60  50  15  5,858  LPC8-60  52  17  10,941  LPC14-60  60  25  18,521                               39      60
            42      65                            LPC4-65  53  15  5,858  LPC8-65  55  17  10,941  LPC14-65  60  22  18,521                               42      65
            45      70                            LPC4-70  56  15  6,474  LPC8-70  58  17  10,941  LPC14-70  60  19  18,521                               45      70
            48      75                            LPC4-75  59  15  6,474  LPC8-75  60  17  10,941  LPC14-75  63  19  18,521                               48      75
            52      80                            LPC4-80  61  15  6,474  LPC8-80  63  16  10,941  LPC14-80  66  19  18,521                               52      80
            56      85                                                 LPC8-85  66  16  10,941  LPC14-85  69  19  18,521         LPC30-85  78  28  41,882  56     85
            60      90                                                 LPC8-90  69  17  10,941  LPC14-90  72  20  18,521         LPC30-90  78  26  41,882  60     90
            64      95                                                 LPC8-95  71  16  10,941  LPC14-95  74  19  18,521         LPC30-95  83  28  41,882  64     95
            68      100                                                LPC8-100  75  17  11,774  LPC14-100 77  19  18,521       LPC30-100 83  25  41,882  68     100
            72      105                                                LPC8-105  78  17  11,774  LPC14-105 80  19  18,521       LPC30-105 89  28  41,882  72     105
            76      110                                                                     LPC14-110 83  19  18,521            LPC30-110 89  25  41,882  76     110
            80      115                                                                     LPC14-115 87  20  18,521            LPC30-115 95  28  41,882  80     115
                    117                                                                     LPC14-117 87  19  18,521            LPC30-117 95  27  41,882         117
            85      120                                                                                                         LPC30-120 95  25  41,882  85     120
                    125                                                                                                         LPC30-125 101 29  41,882         125
            90      130                                                                                                         LPC30-130 101 26  41,882  90     130
            95      135                                                                                                         LPC30-135 104 26  41,882  95     135
                    140                                                                                                         LPC30-140 110 29  41,882         140
            100     145                                                                                                         LPC30-145 110 26  41,882  100    145
            105     150                                                                                                         LPC30-150 116 29  41,882  105    150
            110     155                                                                                                         LPC30-155 116 26  41,882  110    155
                    160                                                                                                         LPC30-160 128 36  44,593         160
            115     165                                                                                                         LPC30-165 128 33  44,593  115    165
            120     170                                                                                                         LPC30-170 128 30  44,593  120    170
                    175                                                                                                         LPC30-175 128 27  44,593         175
