PUNCH – HAND STUD
& BUSHINGS

METAL STUD PUNCHES (MADE IN USA)

FEATURES
• Punch up 1.0mm steel studs in one stroke.
• Aluminium head provides strength with minimum weight,
reducing operator fatigue.
• Contoured handle design gives better operator leverage
and makes it possible to punch in tight places.
• Self-stripping design eliminates punch hang-ups.
J HOLE MAKING & BENDING
• Automatically centres holes on standard studs.
SPECIFICATIONS
Capacity

22280 - 41.3 mm and wider studs.
1.0 mm thick steel studs.
21285 - 63.4 mm and wider studs.

1.0 mm thick steel studs.

Model No. Description Weight
(kg)
22280 22.2mm Diameter Stud Punch 3.2
21285 34.1mm Diameter Stud Punch 3.5
04006 Punch for 22280
22286 Die for 22280
24823 Punch for 21285
21297 Die for 21285
06015 Pin Kit
36617 Link
05932 Link & Pin Kit (22280/21285)
www.specialisedforce.com.au
21557 Compression Spring
BUSHINGS FOR METAL STUD PUNCHES (22280 & 21285)

FEATURES
• Triple lock design holds bushing securely.
• Locks securely into metal studs from 0.55mm to 2.5mm thick.
• Helps protect wire insulation from sharp edges of metal studs.
• Makes pulling smooth and easy by preventing hang-ups of
cable on raw metal edges.

Model No. Model No.
22289 05928
SPECIFICATIONS

Model No. Description Weight (Kg)
22289 1,000 Bushings for 22.2 mm Diameter Hole 1.7
05928 1,000 Bushings for 34.1 mm Diameter Hole 7.0
