PUNCH – BATTERY

MODEL NO. LS100L (BB) BATTERY PUNCH
(MADE IN GERMANY)

The 11-Ton LS100L Battery powered Punch Driver from Greenlee
is the fastest, most powerful knockout driver available on the
market today. Easily punch up to 152.4mm conduit size holes in
mild steel and 101.6mm holes in stainless steel. Using integrated
smart-technology senses when the punch cycle is complete it
automatically shuts off, extending tool life and preventing damage
to the punch and die.
FEATURES

• Up to 2x faster cycle time*
• Powerful 11T punch force
• Compact & ergonomic
• 360º rotating head punches at any angle
• Lightweight at 2.63kg
• “Auto-Stop” avoids damage to punch
• Led light for dark areas J HOLE MAKING & BENDING
• 18V Li-Ion Makita Battery
• Easy one-handed operation with ergonomic tapered grip
• 8 second maximum cycle time
* Compared to similar competitive products
PUNCHING CAPACITY
Punch Size Material Thickness
Material SCAN
(mm OD) (mm) REFER FROM & PLAY
12.7-101.6 3.4 PAGES 346
Mild Steel FOR PUNCHES
127.0-152.4 2.6 AND DIES
12.7-76.2 3.4
Stainless Steel Punches & Dies
88.9-101.6 2.6
Sold Separately
SPECIFICATIONS

Kit Model No. Kit Contents Battery Force (Tonne) Wt (kg) TOOL ONLY
LS100L(BB)* See Below** Makita® 18VDC (Lithium-Ion) 11 2.63
*FOR PUNCHING MILD STEEL UP TO 90mm HOLES ONLY
**KIT CONTENTS

Model No. Description
03138 LS100L Punch Driver & Case (LS100LB)
52176 2 x Battery 18V Li-Ion 3.0Ah
52179 Charger, Battery Li-Ion 230VAC
20963 Draw Stud 3/8” (3/4” Bottom) x 122mm Long
10109 Draw Stud 3/4” x 136.5mm Long (2113B) www.specialisedforce.com.au
03248 Spacer - Short (1924AA)
ABOVE KIT FOR PUNCHING MILD STEEL UP TO 90mm.
SEE BELOW ACCESSORIES FOR LARGER SIZES AND STAINLESS STEEL
ACCESSORIES

MILD STEEL
Model No. Description
03170 Sleeve (1557AA) - For punching holes 102.7 to 161.9mm

STAINLESS STEEL
Model No. Description
29451 Draw Stud - For punching holes up to 22.5mm
29452 Draw Stud - For punching holes up to 28.3 to 90mm
00785 Sleeve (1557SS) - For punching holes up to 102.7 to 115.4mm
