ROLLERS – OH/ABC

OVERHEAD INSULATOR & ABC ROLLERS

ICB-080
ICB-040B

250kg WLL F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT

Insulator Cable Roller

Insulator cable bracket to suit vertical post insulator with top clamp. The unit folds together on a hinge and has a
hand screw up handle. A top ring allows the unit to be carried easily or lowered from pole tops with rope.
The ICB-040B sits close to the top of the insulator where the ICB-080 is raised up higher.

Suits Insulator Necks
Model No. Description Wt (kg)
(mm)
ICB-040B 40mm OD Rollers 55-100 6.1
ICB-080 40mm OD Rollers 55-100 6.5

ABC Roller Guide & Fixing Clamp www.specialisedforce.com.au
Suitable for 4x95mm2 and 4x150mm2 ABC (Aerial Bundled Cable). Assembly is in two parts (Roller Guide & Cable
Clamp). Handle sold separately (See below).

Model No. Description Handle to Suit Model No. ABC-4X150
ABC-4X150 ABC Roller for 4x95-4x150 ABC-H
