Page 151 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

WINCH – CAPSTAN, HYDRAULIC

HYDRAULIC WINCHES (MADE IN USA)

SERIES 1400
For the Utility Industry
HYDRAULIC CAPSTAN
WINCHES

PROUDLY MARKETED, SERVICED

& SUPPORTED AUSTRALIA WIDE
D WINCHES
Series 1400 Gal

Optimum performance on 207Bar Hydraulic System

FAST DEPENDABLE BLOOM WINCHES
• High strength cast iron gear case, with aluminium capstans keyed to alloy steel hardened shafts
• 25:1 and 12.5:1 gear ratios provide versatility in power and speed
• Speeds of up to 30 MPM and pulls of 3,500KG
CUSTOMISED DESIGNED UTILITY WINCHES AND CAPSTANS

Series 1000KC Gal
WARNING! www.specialisedforce.com.au
• Goods are not intended for use in the moving or
lifting of persons! The winches described herein
are neither designed nor intended for use or
Series 1200C application to equipment used in the lifting or
moving of persons and it is understood that all
• Reliable Winches designed for Lifting and such use shall be at the sole risk of the user. The
Pulling applications.. cable clamps on winches are not designed to hold
• Optional Hydraulic Fail-safe and Oil Cooled rated loads. A minimum of 5 wraps of cable must
Disc Brakes available be left on drum barrel to guarantee holding of
• Variety of Motors and drums for optimised rated load.
performance in Utility applications • Applications of winch where life would be
• Speeds of up to 30 MPM and Line Pulls of endangered by any event are not recommended
3,500KG pounds

Please contact your local Specialised Force branch for technical specifications
