SAFETY BARRIER – WINCH

PROTECTIVE CABLE WINCH BARRIER

MODEL No. CWB-600 SERIES CWB- WINCH BARRIER

DESCRIPTION

With Safety the number “1” priority whilst installing cables with high powered winches, these barriers are
designed to provide protection to the operator in the event of rope or cable failure.
Designed for functionality, the barrier can be set-up and adjusted in several configurations to suit your work site
and particular pull.
Other configurations can be made to order. Please contact SF for more detail

D WINCHES

Disassembles flat for
Bullet Hinges, transportation
allows 100°
Rotation of gate

Designed for Greenlee winch
Floor Mount (00865)

FEATURES
• Fabricated from high quality steel product
• Powder coated Safety Orange
• Swivel sides for angle protection forward and backward – can be
assembled on either left or right of the main barrier
• 16mm holes in main base and gate base plates for anchoring and
fixing to winch
• Dissembles flat for ease of transport
• Pictured barrier, designed to suit Greenlee Electric Winch, Floor www.specialisedforce.com.au
Mount (00865)
• Configurations adapted to your Winch and job specifications upon
request
DETAIL

Approximate Dimensions (mm)
Erected 2000H x 1500L x 200W
Disassembled 1000H x 1000L x 200W
Approximate Weight (kg)
Total 35.95
Main Base 17.85
Main Top 8.15
Gate Base 5.6
Gate Top 4.35
