PUMPS – HIGH PRESSURE,
BATTERY & REMOTE

MODEL No. REC-P1(BB) REMOTE BATTERY HYDRAULIC PUMP

C HYDRAULIC TOOLS & ACCESSORIES
The REC-P1(BB) kit has a battery powered hydraulic pump (700Bar)
with hard wired remote control switch, batteries (2 x Li-Ion) and
charger (12/24VDC). A quiet and powerful pump unit, the 28.8VDC
motor provides an intermittent duty hydraulic power source to a
remote head up to 60 ton capacity.
The remote control permits operator to advance, retract and stop the piston at
any desired position. With a 1L reservoir tank it is capable of operating a 60 ton
compression head.
Two batteries must be inserted into the cartridge slots of the pump because they
are connected in series to activate 28.8V DC motor
NOTE: Two BP-80LI battery packs are required to power this pump.
Hoses sold separately

Motor (VDC) 28.8 # REC-P1(BB)
Low Pressure (L/min) 1.8 Kit Contents Description Qty
Oil delivery
High Pressure (L/min) 0.3 REC-P1 Pump & Remote Switch 1
Reservoir volume (L) 1 BP-80LI Battery Li-Ion 2
Oil pressure (Bar) 700 Charging Base , 230VAC Charge
Size LxHxW (mm) 250x380x175 CH-100 Lead & 12/24VDC Charge Lead 1
Weight (kg) 14.0 (less battery
Battery Life Operations (using 2 x BP-80LI Lithium-Ion Batteries)
Tool Head & Sleeve Size Approx. No. of Compressions
EP-410H 150mm2 Cu Sleeve 90
EP-520C 500mm2 Cu Terminal 36 Refer page 54–55 for Battery
EP-60S 6036AH Sleeve 36 and Charger Details Details
Refer 61 for Full Kit Details

Model No.
REC-P1/RCO/BB/CE
FILLED WITH
www.specialisedforce.com.au
PLANTOFLUX
FIRE RESISTANT
HYDRAULIC OIL
Model No.
HP8-408-B38NM-BC

CORDLESS
INFRAREED
Model No. REMOTE
CR-100CE CONTROL

ITEMS SOLD SEPERATELY, REFER TABLE BELOW
Model No. Description

REC-P1/RCO/ Remote Battery pump with 2 x BP-80LI batteries, 2 x CH-100
chargers and Cejn male coupler half. Tagged & filled with
BB/CE Plantoflux fire resistant hydraulic oil shown in picture above
Remote hydraulic cable cutter with Cejn male coupler half.
CR-100CE Cuts up to 100mm diameter steel wire armour cable shown in
picture above
HP8-408- 8m high pressure non-conductive hose assembly with Cejn
B38NM-BC female coupler half each end. Tagged & filled with Plantoflux
fire resistant hydraulic oil shown in picture above
CR100EK Earthing Kit shown below
