SAW – POLE, LONG REACH

LONG REACH POLE CHAIN SAWS (MADE IN USA)

C HYDRAULIC TOOLS & ACCESSORIES
FEATURES
• Cuts hard-to-reach branches from EWP or from the
ground.
• Super Spool™ selector control for use on Open- and
Closed-Centre hydraulic systems.
• Available in two lengths.
• Insulated fibreglass extension tubes, tested to meet
OSHA Regulation 1910.269 with fibreglass tube tested
to 100KVA per 300mm for 5 minutes
• Safety features include: two-step trigger, trigger guard, 520mm
and fully covered sprocket guard.
• Anti-kickback chain and automatic chain oiler.
• Rugged high torque gear motor.
• Internal tube Foam Filled to eliminate moisture ingress.
• Includes flush face couplers “FF”

GREENLEE

IS
FAIRMONT INSULATED

SECTION
(see below)

SPECIFICATIONS

Cutting Capacity 330mm (13”)
Super Spool™ selector control for use on
System Open- and Closed-Centre hydraulic systems
Width (mm) 102
www.specialisedforce.com.au
Flow Range (lpm) 19-30 220mm
Operating Pressure (Bar) 69 - 140
Pressure Port Thread 9/16 - 18 SAE O-Ring
Return Port thread 3/4 - 16 SAE O-Ring

Model No. Description Length Insulated Section Weight
Length (m)
(kg)
(m)
17140/FF Foam Filled Long Reach Chain Saw 1.90 (75”) 1.185 4.6
with M & F Flush Face Couplings
17142/FF Foam Filled Long Reach Chain Saw 2.25 (88.5”) 1.528 4.9
with M & F Flush Face Couplings
