SYSTEM ACCESSORIES |




         IN LINE FLOW CONTROL VALVES                                                         WWW.DURAPAC.COM




  D                                                            Durapac In LIne fLoW controL VaLVeS

                                                               aLLow thE systEm DEsiGNEr GrEat
                                                               fLExibiLity aND coNtroL.
      SYSTEM ACCESSORIES                                       two and four outlet needle valve blocks and check valve with
                                                               Available options include a needle type flow control valve,

                                                               manual by-pass. The VCB-1 load lowering counter balance
                                                               valve offers smooth, chatter free lifting and lowering when used
                                                               with double acting cylinders. It has a pilot pressure adjusting
                                                               range of 50-350 bar and can be mechanically locked once set.



             vCB-1
                                                                                   vMN-4
                                                2 way aluminium bodied manifold with needle valves -
            Load lowering counter balance valve for smooth
            controlled lifting and lowering. Pilot pressure adjusting
                                                2 x 3/8"-NPT female outlet ports, 1 x 3/8"-NPT female
                                                                                   - 4 x 3/8"-NPT female outlet ports, 1 x 3/8"-NPT
                                                                                   female inlet port (centrally located opposite to the 4
            range 50-350 bar. Ports 3/8"-BSP parallel female (pilot   vMN-2        4 way aluminium bodied manifold with needle valves
                                                inlet port (centrally located opposite to the 2 outlet
            port 1/4"-BSP parallel female). Supplied with 2 each   ports)          outlet ports)
            3/8"-BSPP x 3/8"-NPT male nipples
                                                                                                            H 105 mm
                                                                       H 105 mm

                                                                                                 W 352 mm
                                                                 W 150 mm
                                                  D 65 mm

                                                                                D 65 mm
             vNv-1                              RM-7S                              RM-7L
            3/8"-NPT female needle valve        7 port steel bodied return manifold - 7 x 3/8"-NPT   7 port steel bodied return manifold - 7 x 3/8"-NPT
                                                female ports                       female ports







                                                               76     50    3/8"-18NPT*7        203          83
                                              3/8"-18NPT*7  6.3      89               6.3                 184
                                               A                              A
                                            32                            32
                                                A         38  38   38  32     A         102      102     102   32
                                                                                                 369
                                                32            178             32
             vCv-66                             vMN-2M                             vMN-4M
            3/8"-NPT female load lowering check valve with   2 way steel bodied manifold with needle valves - 2   4 way steel bodied manifold with needle valves - 4 x
            manual bypass                       x 3/8”-NPT female outlet ports, 1 x 3/8"-NPT female   3/8"-NPT female outlet ports,
                                                inlet port (centrally located opposite to the 2 outlet   1 x 3/8"-NPT female inlet port (centrally located op-
                                                ports)                             posite to the 4 outlet ports)







                                                         152.4
                                             105.6          76.2            105.6
                                            Opened  Ø 7.1   63.5           Opened  Ø 7.1                63.5
                                                                    Ø 12.7


                                                41.4     76.2    16        28.7  41.4   76.2                 16
                                              98.5            38.1           98.5             279.4          38.1
                                             Closed       127       12.7  41.4  Closed        304.8

         98
