|SYSTEM ACCESSORIES




         WWW.DURAPAC.COM                                          HYDRAULIC GAUGES & HIGH PRESSURE HYDRAULIC HOSES




          HPS Model No.  Bore Size   Lengths      End Types            Colour                                       D
           HPS-0601A*               1 metre
           HPS-0602A*               2 metres
           HPS-0603A*               3 metres
           HPS-0604A*               4 metres
           HPS-0606A*               6 metres
           HPS-0610A*               10 metres
           HPS-0615A*               15 metres
           HPS-0620A*               20 metres
           HPS-0625A*               25 metres  1/4"-NPT - Male thread                    ?
           HPS-0630A*               30 metres     both ends
           HPS-0601B*               1 metre                                                                           SYSTEM ACCESSORIES
           HPS-0602B*               2 metres
           HPS-0603B*               3 metres
           HPS-0604B*               4 metres
           HPS-0606B*               6 metres                                          ThREAD SIZES
                                                                                          !
           HPS-0610B*               10 metres                     * INSERT 'R', 'B' OR 'T'   1/4" & 3/8"-NPT
           HPS-0615B*               15 metres                    AT END OF HOSE MODEL
           HPS-0620B*               20 metres                   NUMBER WHEN ORDERING   9/16"-18UNF
           HPS-0625B*               25 metres  3/8"-NPT - Male thread   TO DEFINE COLOUR   MAXIMUM OPERATING
           HPS-0630B*               30 metres     both ends      CHOICE OR SINGLE/TWIN   PRESSURE
                                                                       HOSE
           HPS-0601C*     1/4"      1 metre                                           700 - 4,000 bar
           HPS-0602C*               2 metres                          R = Red
           HPS-0603C*               3 metres                          B = Black
           HPS-0604C*               4 metres                          T = Twin
           HPS-0606C*               6 metres                       (Red & Black) Fused
           HPS-0610C*               10 metres
           HPS-0615C*               15 metres
           HPS-0620C*               20 metres  CH-6 Male coupling on one
           HPS-0625C*               25 metres  end and other end 3/8"-NPT                i
           HPS-0630C*               30 metres     Male thread
           HPS-0601D*               1 metre
           HPS-0602D*               2 metres
           HPS-0603D*               3 metres
           HPS-0604D*               4 metres
           HPS-0606D*               6 metres                                            Did you know...
           HPS-0610D*               10 metres
           HPS-0615D*               15 metres                                           When using long hose
           HPS-0620D*               20 metres                                           lengths it may be
           HPS-0625D*               25 metres  CH-6 Male coupling on                    necessary to refill the
           HPS-0630D*               30 metres     both ends
           HPS-1001BB               1 metre                                             pump reservoir to allow
           HPS-1002BB               2 metres                                            for the oil that has filled
           HPS-1003BB               3 metres                                            the hose. Allow the
           HPS-1004BB               4 metres                                            following volumes per
           HPS-1006BB               6 metres
           HPS-1010BB               10 metres                                           metre of hose length:
           HPS-1015BB               15 metres                                           HPS-06: 34.21 cc/m
           HPS-1020BB               20 metres                                           HPS-10: 75.43 cc/m
           HPS-1025BB               25 metres
           HPS-1030BB               30 metres  3/8"-NPT Male thread
           HPS-1001CB               1 metre
           HPS-1002CB               2 metres
           HPS-1003CB               3 metres
           HPS-1004CB               4 metres
           HPS-1006CB     3/8"      6 metres                      Available in Black only
           HPS-1010CB               10 metres
           HPS-1015CB               15 metres
           HPS-1020CB               20 metres  CH-6 Male coupling on one
           HPS-1025CB               25 metres   end and other end
           HPS-1030CB               30 metres    3/8"-NPT Male
           HPS-1001DB               1 metre
           HPS-1002DB               2 metres
           HPS-1003DB               3 metres
           HPS-1004DB               4 metres
           HPS-1006DB               6 metres
           HPS-1010DB               10 metres
           HPS-1015DB               15 metres
           HPS-1020DB               20 metres
           HPS-1025DB               25 metres  CH-6 Male coupling on
           HPS-1030DB               30 metres     both ends
