SYSTEM ACCESSORIES |




         HYDRAULIC GAUGES & HIGH PRESSURE HYDRAULIC HOSES                                    WWW.DURAPAC.COM




  D                         GauGes                             thE pg-SerIeS hyDrauLic prEssurE GauGEs

                                                               arE rEcommENDED for moNitoriNG aLL
                                                               hyDrauLic systEms.
      SYSTEM ACCESSORIES  0-14,500 psi 1/4"-NPT Male  100 mm diam. 0-2,700 bar /    feature high quality stainless steel construction. Analogue
                                                               Models are available from 63-150 mm face diameter and
                  PG-63
                                           PG-100-40k
             63 mm diam. 0-1,000 bar /
                                                               models are liquid filled to increase longevity and are accurate
                                         0-40,000 psi 9/16"-18UNF
                                              Female
                                                               to within 1% excluding model PG-63 (1.6%). The battery

                                                               powered PGD-75 digital pressure gauge can be programmed

                                                               with a cylinder effective area and quickly set to read in force
                                                               measurements (kN, tonnes and kgs). It is ideal for testing
                                                               applications requiring a force measurement and is accurate to



                 PG-100                    PG-100-60k          within 0.25%. PG-150                  PGD-75
             100 mm diam. 0-1,000 bar /   100 mm diam. 0-4,000 bar /    150 mm diam. 0-1,000 bar /   75 mm diam. 0-800 bar /
             0-14,500 psi 1/4"-NPT Male  0-60,000 psi 9/16"-18UNF    0-14,500 psi 1/4"-NPT Male  0-11,600 psi 1/4"-NPT Male
                                              Female











                             HOses                             thE HpS-SerIeS hyDrauLic 1/4" & 3/8"
                                                               hosEs arE a hiGh prEssurE thErmopLastic
                                                               hosE that ExcEEDs thE amEricaN
                                                               jacKiNG spEcificatioNs ij100 for usE iN
                                                                                  7
                                                               appLicatioNs to  00 bar.
                                                               The hose is made up by an inner tube that is polyester
                                                               elastomer and is reinforced by braids of aramid fibre plus one
                                                               braid of steel wire covered with a polyurethane (anti abrasive)
                                                               outer. The hose is lightweight and flexible with a tight bend
                                                               radius for use on hose reels and in tight situations.
                                                               1/4" sizes are available in Red, Black and Twin (1 x Red / 1 x
                                                               Black) for double acting hydraulic applications. All hoses are
                                                               complete with crimp on fittings and bend restrictors. Models
                                                               complete with hydraulic couplings are available (see table for
                                                               details).











                            Internal    Outside   Working Pressure  Min. Burst   Safety   Temperature    Bend
                  Hose Size                                 Pressure                 Range                Weight
          Model No.         Diameter  Diameter                         Factor                      Radius
                    (inch)                                                                                (g/m)
                             (mm)     (mm)   (bar)  (psi)  (bar)  (psi)  Ratio  (min.)    (max.)   (mm)
          HPS-06     1/4      6.6     12.7   700   10,000  2,800 40,000  4:1    -40 °C   +100 °C    35     180
          HPS-10     3/8      9.8     18.7   700   10,000  2,800 40,000  4:1    -40 °C   +100 °C    90     330

         96
