PD |SERIES




         WWW.DURAPAC.COM                                                         DIESEL DRIVEN RAILWAY POWER UNITS
           ?



         thE pDM3054-raIL DiEsEL DrivEN raiLway                                                                     C
         powEr uNit is suitabLE for hEavy Duty
         appLicatioNs iN thE fiELD aND caN DELivEr a
         miNimum fLow of 2.5 Lpm at 700 bar prEssurE.                                                                 PUMPS
           !
         It is specifically designed to operate rail tensors and weld shears
         commonly used in the railway industry. It features a selector valve
         to choose which tool to operate and individual directional control
         valves for each tool. Tools can be single or double acting and
         each tool may have a different maximum operating pressure.


                                                                                      MOTOR SIZE
           i           Did you know...                                                FLOW
                                                                                      3.4 kW

                                                                                      2.5 Lpm
                       Durapac diesel power units can be custom designed to suit
                       many applications. variations in function, pressure and flow
                                                                                      PRESSURE
                       can be achieved. Consult Durapac for more information.         MAXIMUM OPERATING
                                                                                      700 bar

                                                                                                TENSOR OUTLET













          WELD ShEAR OUTLET
                                                                                               SELECTOR vALvE
                                                                                                   choose between
                                                                                                 tensor or weld shear























                                          Flow Rate   Maximum   Valve Types
                         Motor                                              Usable Oil   Approx. Dry
           Model Number         kW   rpm   (Lpm)  @   Pressure   (3/8"-NPTF Ports)            Approx. Dimensions (mm)
                         Type                                              Capacity (L) Weight (kg)
                                           700 bar  Rating (bar)*
                                                                 Selector
          PDM3054-RAIL  Diesel  3.4  2,200   2.5      700        Shear**      50       190     450 W x 750 L x 650 H
                                                                Tension**
         *  Specify tool working pressure at placement of order.
         ** Specify single or double acting tools at placement of order.                                      91
