DPR |SERIES




         ROTARY AIR HYDRAULIC POWER UNITS                                                    WWW.DURAPAC.COM




   C                                                           thE Dpr-SerIeS rotary air DrivEN powEr

                                                               uNits arE a two spEED hiGh pErformaNcE
                                                               pump DEsiGN.
      PUMPS                                                    They are ideally suited to applications where air is the preferred

                                                               power source. A choice of valve configurations allows them
                                                               to be used with single or double acting cylinders and tools.
                                                               Optional valve sub-plates offer pressure and flow control. All
                                                               models feature a Gast heavy duty air motor with a slide type
                                                                                ®
                                                               motor ON/OFF air supply valve and 11 L usable oil reservoir.




























































                                                     Maximum    Pressure Rating    Oil Output Flow Rate                                                          Air
                      Used with   Motor Size   Usable Oil                                                                                          Air Pressure          Sound                    Dimensions (mm)                Weight
           Model No.                                 Pressure       (bar)             (Lpm)           Valve Type                    Valve Function           Consumption
                      Cylinder   (kW)    Capacity (L)                                                                                              Range (bar)          Level (dB)                                                (kg)
                                                    Rating (bar)  1st Stage  2nd Stage   1st Stage   2nd Stage                                                  (Lpm)              A     B      C      D      E      F     G
          DPR-222       S/A       1.27     11.0        700       48     700       5.1       0.36       Dump                         Advance/Return  4.1 – 5.6   1,246     93       -     303   212    184    305    313    456    24
          DPR-223       S/A       1.27     11.0        700       48     700       6.8       0.36    Manual 3w/3p                  Advance/Hold/Return  4.1 – 5.6  1,246   93       -     292   208    184    305    313     -     24

          DPR-224       D/A       1.27     11.0        700       48     700       6.8       0.36    Manual 4w/3p                  Advance/Hold/Return  4.1 – 5.6  1,246   93      362    295   208    184    305    313    459    24
