PE |SERIES




         WWW.DURAPAC.COM                                                     SINGLE SPEED RADIAL PISTON POWER UNITS




                                                                                                                    C
         thE SIngLe SpeeD raDiaL pistoN powEr uNits offEr a raNGE of
         fLow aND powEr optioNs to suit maNy iNDustriaL appLicatioNs.
         These power units are suitable for heavy duty applications and offer flows from 0.95 Lpm to
         8.10 Lpm at 700 bar pressure. Valve options for operating single and double acting cylinders                 PUMPS
         are available in manual or solenoid control.








                                                                                      MOTOR SIZE
                                                                                      0.84 - 11 kW

                                                                                      FLOW
                                                                                      0.73 - 8.1 Lpm@700 bar
                                                                                      MAXIMUM OPERATING
                                                                                      PRESSURE
                                                                                      700 bar


         thE SpLIt fLoW powEr uNit offErs
         syNchroNisED LiftiNG aND LowEriNG of
         LoaDs rEGarDLEss of wEiGht DistributioN.
         Power is provided by a single electric motor to a single pump
         body incorporating 4 pressure outlets. Oil flow per outlet is
         identical for each revolution of the electric motor. The split flow
         power unit provides a simple effective solution to critical lifting
         and lowering applications. Manual valve options for double
         acting cylinders are standard and solenoid control is optional.
         Durapac also offers other split combinations such as 2 way, 6
         way and 8 way.




                                                                   Valve Type  Usable Oil  Approx. Dry
                    Flow Rate  Pressure   Motor kW @  Voltage   Pendant                         Approx. Dimensions
           Model No.                                Amps          Sol.= Solenoid   Cap.   Weight
                     (Lpm)  Rating (bar)  1,450 rpm  (50 Hz)  Control                                (mm)
                                                                  Man.= Manual  (L)    (kg)
          RADIAL SINGLE SPEED SERIES
          PEMR1523     0.95   700      1.5      240   8.3  MOTOR    3w/3p Man.  20     53     300 W x 450 L x 605 H
          PEMR1524     0.95   700      1.5      240   8.3  ON/OFF  4w/3p Man.  20      53     300 W x 450 L x 605 H
                                                          SOLENOID
          PESR1523     0.95   700      1.5      240   8.3  ADV/HOLD/  3w/3p Sol.  20   59     300 W x 450 L x 605 H
          PESR1524     0.95   700      1.5      240   8.3  RETRACT  4w/3p Sol.  20     59     300 W x 450 L x 605 H
          PEMR3023     1.75   700      3.0      415   6.3    *     3w/3p Man.  20      55     320 W x 450 L x 560 H
          PEMR3024     1.75   700      3.0      415   6.3    *     4w/3p Man.  20      55     320 W x 450 L x 560 H
          PESR3023     1.75   700      3.0      415   6.3  ADV/HOLD/  3w/3p Sol.  20   61     320 W x 450 L x 560 H
                                                          SOLENOID
          PESR3024     1.75   700      3.0      415   6.3  RETRACT  4w/3p Sol.  20     61     320 W x 450 L x 560 H
          PEMR5553     3.97   700      5.5      415  11.3    *     3w/3p Man.  50      99     270 W x 440 L x 750 H
          PEMR5554     3.97   700      5.5      415  11.3    *     4w/3p Man.  50      99     270 W x 440 L x 750 H
          PESR5553     3.97   700      5.5      415  11.3  ADV/HOLD/  3w/3p Sol.  50   105    270 W x 440 L x 750 H
                                                          SOLENOID
          PESR5554     3.97   700      5.5      415  11.3  RETRACT  4w/3p Sol.  50     105    270 W x 440 L x 750 H
          PEMR11103    8.10   700       11      415  19.8   **     3w/3p Man.  100     **             **
          PEMR11104    8.10   700       11      415  19.8   **     4w/3p Man.  100     **             **
                                                          SOLENOID
          PESR11103    8.10   700       11      415  19.8  ADV/HOLD/  3w/3p Sol.  100  **             **
          PESR11104    8.10   700       11      415  19.8  RETRACT  4w/3p Sol.  100    **             **
          SPLIT FLOW SERIES
          PEMS4054  4 x 0.73  700      4.0      415  8.85    *     4w/3p Man.  50      180    440 W x 750 L x 710 H
         *  Standard supply is motor mounted ON/OFF/JOG switch. Remote pendant is optional.
          To order with remote pendant; add "R" to the end of the model number.
         ** Consult Durapac.                                                                                  83
