SPE |SERIES




         ELECTRIC HYDRAULIC POWER UNITS                                                      WWW.DURAPAC.COM




   C                                                            thE Spe 45 -SerIeS powEr uNits arE
                                                                coNfiGurED with a NumbEr of vaLvE aND
                                                                pump fuNctioNaLity optioNs to ENsurE
      PUMPS                                                     appLicatioN.
                                                                that thErE is a suitabLE pump for EvEry

                                                                Cost effective, portable and powerful these units are
                                                                lightweight and have a carry handle integrated into the shroud.                         2.5m
                                                                Extremely simple to use. Pressure switch, adjustable pressure
                                                                relief and pilot check valves are available options on the 45
                                                                Series.                                                                                                                  UP
                                                                                                                                                                                                 212  262
                                                                                                                                                                                         DOWN






                                                                                                                                                                              212
                                                                                                                                                        ON                    262














                                                                                                                                                                                                    342




                                                                                                                                                                                             117.5  145


                                       Pressure   kW @                Flow Rate (Lpm)      Usable Oil   *Optional Large
          Model    Electric Motor (50/60 Hz)  Rating   2,000   † Voltage  Amps      Fitted   Capacity   Tank Usable Oil                     170                               170           4-M6-T7
                                                                                    with
                                        (bar)   rpm                   70 bar  700 bar         (L)    Capacity (L)
                                                                                                                                            210                               194
          SPE45   Single phase, commutator   700  0.45  230     4.5   2.5    0.35  Pressure   2          3
          Series  type, insulation class 120 (“E")      110      9                  Gauge

                         Valve Type   Used                                                  Remote Pendant   Weight
           Model Number  Sol. = Solenoid    with              Pump Function                 Function 2.4 mtr  (kg)
                       Man. = Manual  Cylinder
          SPEM4505M        Basic     S/A                 P.T. manifold, without valve       MOTOR ON/OFF   16.3
          SPEM45053     3w/2p Man.   S/A             Advance, Hold, Retract via manual valve  MOTOR ON/OFF  18.1
                                              “Advance" when ON switch is pressed and the motor starts,
          SPES4505NC     3w/2p Sol.  S/A    Release ON switch to “Hold" and stop the motor, “Retract" when   Adv/Hold/Retract  19.2
                                                           OFF switch is pressed
                                            “Advance" when ON switch is pressed and the motor starts, Auto
          SPES4505NO     2w/2p Sol.  S/A                                                    MOTOR ON/OFF   20.5
                                                      “Retract" when ON switch is released
          SPEM45054     4w/3p Man.   D/A             Advance, Hold, Retract via manual valve  MOTOR ON/OFF  18.1
                                              “Advance"/"A" port Hold/ “Retract" with stacking type pilot-
          SPES45054SP    4w/3p Sol.  D/A                                                    Adv/Hold/Retract  20.5
                                                    operated check valve fitted on “A" port line
                                             “Advance"/"A" and “B" port Hold/ “Retract" with stacking type
          SPES45054WP    4w/3p Sol.  D/A   pilot-operated check valve fitted on “A" and “B" port lines. Pressure  Adv/Hold/Retract  20.5
                                                       holding on both “A" and “B" ports

                                                               * To order with larger tank size; add "L" to the end of the model number
         78                             †  Standard motor supplied is 230V, should 110V be required; add "110V" to the end of the model number
