REMOTE CUTTING HEADS

CU/AL CU/AL
MODEL No. P-132 Only MODEL No. P-85 Only MODEL No. P-105YC
CU/AL
Only

INCLUDED ITEMS INCLUDED ITEMS INCLUDED ITEMS
Cutter & Carry Bag Cutter & Carry Bag Cutter and Vinyl Carry Bag

SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
Output Force (kN) 95 Output Force (kN) 41 Output Force (kN) 117
Maximum Input Pressure Maximum Input 685 Maximum Input Pressure
(bar) 700 Pressure (bar) (bar) 700
Oil Volume Required (cc) 220 Oil Volume Required (cc) 65 Oil Volume Required (cc) 105
Size (mm) 630 (L) Size (mm) 455 (L) Size (mm) 535 (L) B CABLE CUTTING
Weight (kg) 12.0 Weight (kg) 7.2 Weight (kg) 7.9

FEATURES FEATURES FEATURES
P-132 hydraulic cutter Quickly cut up to 85mm OD cut P-105YC scissors type cutter
head cuts insulated cables with remote operation, can be head was designed to cut
up to 132mmOD. It cuts operated with HP pump. various cables used in the
underground or armoured Guillotine type cutting for less industry today.
cables (depends on type). jamming than shear type cutting. Cut up to 105mm OD cable (not

It has fast cutting action with It can be operated by any hydraulic steel core). The scissors type
remote operation. Guillotine type pump with rated oil pressure of cutter head provides exceptional
cutting for less jamming than 700 Bar. The blades are easily ease of use and manoeuvrability
shear type cutting. 132mm jaw replaceable and is a lock pin type when making cuts. It can cut the
opening accepts larger size cables. cutter head. cables with a minimum amount of
The head can be operated by distortion. Handle stand support
any hydraulic pump with rated oil DETAILS helps operation with hands and on
pressure of 700 Bar. The blades are Cutting of piano wire is prohibited. ground.
easily replaceable and the head is a
lock pin type cutter head. DETAILS
Cutting Capacity
DETAILS Material mmOD Cutting of piano wire is prohibited.
Cu strands* 28
Cutting of piano wire is prohibited.
Al strands* 38 Cutting Capacity www.specialisedforce.com.au
Cutting Capacity CCP cable 85 Material mmOD
Material* mmOD * Will cut AL & CU strands up to 85mm OD Cu strands 105
Cu strands 100 depending on cable type. Al strands 105
Al strands 130 Please contact Specialised Force for more
* Cuts some ‘SWA’ (Steel Wire Armoured) information.
contact your nearest Specialised Force branch.

• Refer page 116–117 for hydraulic coupling configurations and hoses,
supplied standard with screw type female 3050-3 coupling
• Battery or Electric pumps, refer page 106 to 112
