GUILLOTINE CUTTERS –
BATTERY

BATTERY GUILLOTINE CUTTERS (MADE IN JAPAN)

MODEL NO. S7G SERIES

The S7G series battery Hydraulic cutter can be used for cutting
a variety of sizes & types of material, up to 40mm OD including,
copper (CU), Aluminium (AL), ACSR, Guy Wire, Re-bar and Wire
Rope. The pistol style tools are well balanced and are suited
for many applications. The trigger switch and return button are
activated using one hand, leaving the other hand free to secure
working material. Battery level is indicated on the Makita battery.

To order complete kits including Cutter, two Batteries, 230VAC
Charger and Carry Case - use “Kit Model No.” shown in tables below
(add suffix “BB”).

“Series 7 battery cutter provides the IZUMI reliability with
the versatility of a Makita battery”

FEATURES

• Japanese quality • Manual retract does not rely on battery B CABLE CUTTING
• Lightweight • Battery level indicator (on battery)
• Retract stop feature for multiple cuts • Powered by a genuine MAKITA™ 18V lithium-ion battery
• Swivel head • Ergonomically designed & balanced body for operator comfort
• Quality backed by ISO9001

CUTTING SPECIFICATIONS

Maximum Cutting Capacity for Material Type (mm)

Force Opening
Kit Model No. Style Cuts
(kN) Ø (mm) 6x7 Wire Rope 6x12 Wire Rope 6x19 Wire Rope Soft Steel Bar to 500Mpa) ReBar (400 (650Mpa) Rebar Cu Strands Al Strands ACSR Guy Wire 1x7 1x19 Guy Wire

Al/Cu/ACSR/
S7G-S40M(BB) Guillotine 70 Wire Rope/Soft 40 22 22 22 20 16 9.6 40 40 38 15 20
Steel Bar/Guy
Wire/ReBar
NOTE: For special cables or conductors contact Specialised Force and we can test cut materials and suggest most suitable models
TOOL SPECIFICATIONS

Ram Stroke Reservoir Dimensions Weight Including
Kit Model No. Battery Details Battery Brand
(mm) Capacity (cc) (mm) Battery (kg)
S7G-S40M(BB) 40 135 445 x 297 x 92 6.9 18.0V Li-Ion Makita www.specialisedforce.com.au

ACCESSORIES

Model No. Description
BL1850B Makita 18V 5.0Ah Battery
DC18RC Makita 230V Battery Charger
BL1850B DC18RC
