P. 59
IN-LINE CUTTERS - BATTERY
INLINE BATTERY CUTTERS (MADE IN JAPAN)
MODEL NO. SL SERIES
The Izumi SL series slimline hydraulic cutters were designed
for ease of cutting overhead conductors, underground cables,
wires and ropes. Smaller models can be used with one
hand. They are also ideal for cutting in tight spaces such as
switchboards, panels or pre-existing cable termination points.
The operation switch is easily activated and your other hand
is free to align and manoeuvre cutting material.
Despite their lightweight “in-line” compact design, their
performance is still strong. Battery power (BP-80LI) has been
increased by 40% (when compared to the REC-5 Series).
Most series 6 models feature new electronic circuit boards,
improved powerful gear reduction magnetic motors with SL-ND/GW SL-ND/ACSR SLS-20 SL-S40 SL-95YC
overload protection and lithium-Ion battery capacity indicator. SL-ND/CH
To order complete kits with tool, two batteries,
12VDC-230VAC charger and carrying case - use
“Kit Model No.” in tables below (suffix (BB)).
FEATURES
• Upgraded Electronic Circuit Boards
• Powerful Magnetic Motors with Overload Protection Latching Pin Style B CABLE CUTTING
• Ergonomic Hand Grip Design Rapid ram advance Scissor Head Scissor Head Guillotine Guillotine Scissor Head
mechanism Head Head
• Right or left handed operation
• 180° swivel head
• Quality backed by ISO9001
• LED light
• Battery Charge: Increased by 40% (when SCAN
compared with the REC-5 Series) & PLAY
• 230VAC & 12/24VDC Charge Leads Included with
Charge Base (“BB” kit models)
• 14.4VDC 3.0Ah Lithium-Ion Batteries have Press SL-S40 LED LIGHT SL-95YC LED LIGHT
Button Charge Indicator
• Safety Trigger
CUTTING SPECIFICATIONS
Maximum Cutting Capacity for Material Type (mm)*
Force Opening
Kit Model No. Style Cuts
(kN) Ø (mm) Wire Rope 6x7 6x12 Wire Rope 6x19 Wire Rope Soft Steel Bar 500 Mpa) ReBar (400 to (650Mpa) Rebar Cu Strands Al Strands ACSR Guy Wire 1x7 Guy Wire 1x19
SLS-20(BB) Guillotine 66 Al/Cu/ACSR 20 16 20 20 16 13 10 20 20 20 15 16
SL-S40(BB) Guillotine 70 Al/Cu/ACSR 40 22 22 22 20 16 N/A 40 40 38 15 20
SL-95YC(BB) Scissor 120 Al/Cu 95 N/A N/A N/A N/A N/A N/A 95 95 N/A N/A N/A www.specialisedforce.com.au
SL-ND/ACSR (BB) Scissor 70 Al/Cu/ACSR 21 N/A N/A N/A N/A N/A N/A 14 14 20 N/A N/A
SL-ND/CH(BB) Scissor 70 Al/Cu 32 N/A N/A N/A N/A N/A N/A 32 32 N/A N/A N/A
SL-ND/GW(BB) Scissor 70 Al/Cu/ACSR 19.5 N/A N/A N/A 9.3 9.3 N/A 14.3 14.3 14.3 9.3 9.3
* For special cables or conductors contact Specialised Force and we can test cut materials and suggest most suitable models
TOOL SPECIFICATIONS
Kit Model No. Ram Stroke (mm) Blade Opening (mm) Reservoir Capacity (cc) Dimensions (mm) Weight Including Battery (kg)
SLS-20(BB) 20 - 100 414x95x70 3.6
SL-S40(BB) 40 - 166 530x121x101 5.7
SL-95YC(BB) - 95 153 685x250x120 9.4
SL-ND/ACSR (BB) - 21 45 554x110x80 3.5
SL-ND/CH(BB) - 32 45 554x110x80 3.5
SL-ND/GW(BB) - 19.5 45 554x110x80 3.5
Refer page 54–55 for battery and charger details
