DRILL ACCESSORIES –
MAGNETIC

ANNULAR CUTTERS FOR HMD SERIES (MADE IN USA)

HMD904 & HMD914 Annular Cutters HMD150 Annular Cutters Pilots
Trak-Star Annular Cutters for magnetic drills
and many competitive brands. These tools RotaLoc Plus Annular Cutters are
feature an aggressive tooth geometry for made from hardened M2 HSS For use with the HMD series
faster cutting. They are made from high and feature the quick change magnetic drills.
quality hardened M2 HSS and have a 3/4” shank for fast tool change outs.
two flat shank. 50mm depth. J HOLE MAKING & BENDING

ANNULAR CUTTERS FOR HMD904 & ANNULAR CUTTERS FOR HMD150
HMD914 Model No. Cutter OD (mm) Decimal Equiv.

25mm 50mm Decimal Use Pilot # 17470
Model No. Model No. Cutter OD (mm) Equiv. 17400 12 0.4724
10531 10532 Pilot Model No. 17402 13 0.5118
12312 12412 12 0.4724 17404 14 0.5512
10533 10534 Pilot Model No. 17406 15 0.5906
12313 12413 13 0.5118 17408 16 0.6299
12314 12414 14 0.5512 17410 17 0.6693
12315 12415 15 0.5906 17412 18 0.7087
12316 12416 16 0.6299 17414 19 0.748
12317 12417 17 0.6693 17416 20 0.7874
12318 12418 18 0.7087 17418 21 0.8268
10527 10528 Pilot Model No. 17420 22 0.8661
12319 12419 19 0.748 17422 23 0.9055
12320 12420 20 0.7874 17424 24 0.9449
12321 12421 21 0.8268 17425 24.5 0.9645
12322 12422 22 0.8661 17426 25 0.9843
12323 12423 23 0.9055 17428 26 1.0236
12324 12424 24 0.9449 17430 27 1.063
12325 12425 25 0.9843 17432 28 1.1024
12326 12426 26 1.0236 17434 29 1.1417
12327 12427 27 1.063 17436 30 1.1811
12328 12428 28 1.1024 17438 31 1.2205
12329 12429 29 1.1417 17440 32 1.2598
12330 12430 30 1.1811 17442 33 1.2992
12331 12431 31 1.2205 17444 34 1.3386
12332 12432 32 1.2598 17446 35 1.3779
12333 12433 33 1.2992
12334 12434 34 1.3386 PILOTS FOR HMD150 www.specialisedforce.com.au
12335 12435 35 1.3779
12336 12436 36 1.4173 Model No. Description
12337 12437 37 1.4567 17100 Standard Pilot for HMD115
12338 12438 38 1.4961 17101 Spring Ejection Pilot*
12339 12439 39 1.5354 17470 For use with HMD150
12340 12440 40 1.5743
12341 12441 41 1.6142 PILOTS FOR HMD904 & HMD914
12342 12442 42 1.6535
12343 12443 43 1.6929 CUTTERS
12344 12444 44 1.7323
12345 12445 45 1.7717 Model No. Description
12346 12446 46 1.811 10527 25.4mm D.O.C. Pilot (19mm - 52mm)
12347 12447 47 1.8504 10528 50.8mm D.O.C. Pilot (19mm - 52mm)
12348 12448 48 1.8898 10531 25.4mm D.O.C. Pilot (12mm)
12349 12449 49 1.9291 10532 50.8mm D.O.C. Pilot (12mm)
12350 12450 50 1.9685 10533 25.4mm D.O.C. Pilot (13mm - 18mm)
12351 12451 51 2.0079 10534 50.8mm D.O.C. Pilot (13mm - 18mm)
12352 12452 52 2.0472 24131 76.2mm D.O.C. Pilot (19mm - 52mm)
