DRILLS – FLEXIBLE

D’VERSIBIT SYSTEM
(MADE IN THE USA)

FEATURES

A new twist to an old problem.
These flexible steel drill bits are the right tools for installing
wire or cable inside existing walls.

It bends to meet your needs!
J HOLE MAKING & BENDING
Fishing wire or cable through existing walls used to be
frustrating and time-consuming, but the D’VersiBIT has made
it as simple as bowing the spring steel shaft in the direction
you want to drill and turning on the power. Proven in the
field to deliver accurate and professional results in many
applications. Bits range from 4.8 to 25.4 mm in diameter and
in shaft length from 304.8 to 1828.8 mm.

The D’VersiBIT System makes it possible to easily
accomplish even complex installations. This patented system
attaches a quality drill bit to a long flexible spring steel shaft.
When used with the Placement Tool, this flexibility makes it
possible to easily manipulate the bit within walls. After drilling,
attach a D’VersiGRIP to the hole in the drill and pull wire or
cable back through the wall.

TECHNICAL INFORMATION

Type A, Auger Type B, Combination with Screw Point

• Wood-type auger bit with screw point. • For aggressive chip removal in many types of woods.
• Pulls itself through wood, avoids walking or skidding. • Screw point for easy starting and pulling through wood.
www.specialisedforce.com.au
• Excellent for drilling in soft woods or through thin sections. • With screw point removed, this bit can be ground to function like a
• Slow back-taper allows for easy retrieval. standard combination bit.
SPECIFICATIONS

Type A Type B
Bit Diameter Colour Code Shaft Length Shaft Diameter
Auger Combination with Screw Point
mm mm mm Model No. Model No.
6.4 914 4.0 - -
6.4 1371 4.0 - -
6.4 1828 4.0 - -
9.5 1371 4.8 38068 38093
9.5 1828 4.8 38069 38094
12.7 914 4.8 38072 38097
12.7 1371 4.8 38073 38098
12.7 1828 4.8 38074 38099
14.3 1371 4.8 38078 38103
14.3 1828 4.8 38079 38104
19.1 914 6.4 38082 -
19.1 1371 6.4 38083 -
19.1 1828 6.4 38084 -
25.4 1371 6.4 38088 -
25.4 1828 6.4 38089 -
Bits are colour coded (Blue, Black, Green, Orange, Red & White)
