DRILLS – MAGNETIC

MAGNETIC DRILLS MD SERIES (MADE IN USA)

Trak-Star offers three magnetic
drills for holemaking. The Low
profile HMD150 is lightweight
and easily fits into tight
areas. The HMD904 is the SCAN
best all round drill for general & PLAY
J HOLE MAKING & BENDING
fabrication. The powerful
HMD914 makes large deep
holes in heavy duty fabrication HMD914 HMD904 HMD150
environments.
MODEL HMD150 LOW PROFILE MAGNETIC DRILL

Features Specifications
Electric 230VAC, 50Hz, 9A, 1035W
Patented quill feed arbor for smooth Motor 8A, 450RPM
cuts and minimal maintenance. Uses Diameter (mm) 12-35
RotaLoc Plus™ cutters which require
no tools for installation or removal. Depth (mm) 25
Positive slug ejection, high torque Cutter/Mount Rotaloc Plus
gearing with lift detector safety Dimensions (mm) 198H x 165W x 297L
system. Feed handle switches easily
from side to side. Ratchet or wrench Magnet
can be used in place of feed handle. Base (mm) 102W x 178L
Rear mounted controls. Lightweight Power
with ergonomic carrying handle.
Carrying case included with one year 25mm Plate Dead Lift – 982kg
warranty. 9.5mm Plate Dead Lift – 544kg
Weight (kg) 10.3
MODEL HMD904 MAGNETIC DRILL
Features Specifications
Electric 230VAC, 50Hz, 9A, 1035W
Motor 8A, 450RPM
Diameter (mm) 12-38
Large 38.1 x 50.8mm capacity. Depth (mm) 50
Uses Mag Drill Annular Cutters. Cutter/Mount 19mm Shank Annular Cutters
www.specialisedforce.com.au
Positive slug ejection. Durable and
powerful magnet. Wide range of Dimensions (mm) 416H x 183W x 210L
accessories are available. Feed Magnet
handles quickly change from side Base (mm) 102W x 178L
to side. Lift detector safety system
with rear mounted controls. Gravity Power
fed coolant system. Carrying case Dead Lift – 794kg
included with one year warranty. 25mm Plate Drilllpoint Breakaway 433kg
Dead Lift – 594kg
9.5mm Plate Drilllpoint Breakaway 322kg
Weight (kg) 12.5
MODEL HMD914 MAGNETIC DRILL
Features Specifications
Electric 230VAC, 50Hz, 12.2A, 1403W
Motor 11.2A, 350RPM
Diameter (mm) 12-52
52.4mm diameter x 76.2mm depth. Depth (mm) 76
Powerful high torque motor and
gears. Uses Mag Drill Annular Cutter/Mount 19mm Shank Annular Cutters
Cutters. Positive slug ejection. Dimensions (mm) 584H x 191W x 311L
Feed handles quickly change from Magnet
side to side. Lift detector safety
system. Rear mounted controls. Base (mm) 89W x 197L
Gravity fed coolant bottle supplied. Power
Carrying case included with one Dead Lift – 1012kg
year warranty. 25mm Plate Drilllpoint Breakaway 535kg
Dead Lift – 565kg
9.5mm Plate Drilllpoint Breakaway 361kg
Weight (kg) 18.6
