DRILL & TAP COMBINATIONS

COMBINATION DRILL/TAP BITS (MADE IN THE USA)

FEATURES
• Drill, Tap, and Countersink in one easy to use bit.
• Tap holes up to 4X’s faster than traditional methods.
• One-piece Drill/Tap design ensures proper hole
size for threaded tap size.
• Available in kits and individual bits metric and DRILL, TAP &
imperial thread sizes. COUNTERSINK
J HOLE MAKING & BENDING
• Constructed of hardened High Speed Steel. UP TO
• Long length Drill/Tap Bits tap up to 12.7 mm “4 X” FASTER
(1/2”) thick material.
• Split-tip drills fast and resists walking.
• Back tapered beyond tap to prevent thread
damage.
• Quickly deburrs and countersinks threaded hole.
• Fast, secure 1/4” Quick-Change hex shank.
• Quick-Change adapter included in Standard Length,
Long Length, and Metric Drill/Tap Kits.
• For best results, use cutting oil with all Drill/Tap bits.

SPECIFICATIONS

Model No. Description 17620 DTAPKIT 12151 DTAPKITM
Kits
12151 M3-M10, 6 Piece Drill/Tap Set 
17620 6-32 to ¼-20 6 Piece Drill Tap Set 
Individual & Replacements
www.specialisedforce.com.au
17611 6-32UNC 
17612 8-32UNC 
17613 10-24UNC 
17614 10-32UNC 
17615 12-24UNC 
17616 ¼-20UNC 
11627 5/16 x 18UNC
11628 3/8-16UNC
12160 M3 x 0.50 
12161 M4 x0.70 
12162 M5 x 0.80 
12163 M6 x 1.00 
12164 M8 x 1.25 
12165 M10 x 1.50 

To extend the life of your tool, use Cutting/Threading Oil.
