DIES 6T

6 TON ROUND DIES

SUITS KKT SL150HP, KLAUKE EK425, IZUMI SL-ND
DOES NOT SUIT IZUMI 5 TONNE TOOLS

COPPER

Dimensions Of Hex Die (mm)
Model No. Cond Details (mm²)
A/F Crimp Length
Refer to Page 50 for More Information on the Cutting Heads 6T-6.3AFCU 6.3 6.0 16
6T-7.7AFCU 7.7 10.0 25
6T-9.2AFCU 9.2 10.0 35
6T-10.4AFCU 10.4 9.0 50
6T-11.5AFCU 11.5 9.0 70
6T-14.2AFCU 14.2 6.0 95
6T-16.5AFCU 16.5 6.0 120
6T-18.3AFCU 18.3 5.0 150
6T-20.0AFCU 20.0 5.0 185
6T-23.1AFCU 23.1 5.0 240
6T-CUSET240 COPPER DIE SET INCLUDES ALL DIES ABOVE A CABLE CRIMPING

ALUMINIUM
Dimensions Of Hex Die (mm)
Model No. Cond Details (mm²)
A/F Crimp Length
6T-9.0AFAL 9.0 12.0 10-35
6T-13.2AFAL 13.2 12.0 50-70
6T-17.3AFAL 17.3 9.0 95-120
6T-22.0AFAL 22.0 9.0 150-185

ABC – PRE-INSULATED SLEEVES
Dimensions Of Hex Die (mm)
Model No. Cond Details (mm²)
A/F Crimp Length
6T-14.0AFALABC 14.0 9.0 25
6T-17.3AFALABC 17.3 9.0 35-70
6T-21.5AFALABC 21.5 9.0 95-150 www.specialisedforce.com.au

6T-CUSET240
