BATTERY CRIMPER/
CUTTER – 6T

MODEL No. SL-ND

SL-ND
6T Crimp
Tool (only)

SL-6CJ SL-ACSR SL-CH SL-GW
FORCE
6 Tonne 6T Crimp Cut ACSR Cut Al/Cu Cut Al/Cu/ACSR
BATTERY TYPE & CAPACITY Refer to Page 50 for More Information on the Cutting Heads
Lithium-Ion 14.4VDC 3.0Ah
CAPACITY SPECIFICATIONS
Crimp # SL-6CJ head up to 240mm2
14.4
Motor (V D C)
Al/Cu/ACSR Force at die face (kN) 3.6 (Inc battery) Simple Spring
70
A CABLE CRIMPING FEATURES Battery Capacity (Ah) 3.0 (Lithium-Ion) Loaded Twist
Cut # SL-CH up to 32mm OD
Cu/Al 300mm2
89 x 560 x 69
Size (mm)
# SL-ACSR up to 20mm OD
Weight (kg)
ACSR (Single Steel Core)
# SL-GW up to 14.3mm
Pin Design for
1.0
Cu/Al/ACSR
Charge Time (hrs)
Changing Head
The SL-ND was designed light and ergonomic, to be used one-handed and operated in confined spaces.

•
The SL-ND has four interchangeable jaw types: SL-6CJ Jaw for
The SL-6CJ Jaw accommodates 6 ton round type dies for
•
crimping (6T capacity); SL-CH jaw for cutting Al/Cu; SL-ACSR
applying compression fittings to copper, aluminum, and ACSR
•
Quickly and easily change between head types with the easy
The SL-ND also features an LED light for illuminating dark work
pull-pin design.
areas and a fully enclosed weather resistant housing.
• for cutting ACSR; and SL-GW for cutting Al/Cu/ACSR. • conductors widely used in the industry (Also crimps ABC).
Number of crimps per battery charge for maximum
Powered by a Lithium-Ion battery.
•
size terminals: Approximately 100. • Jaws are sold seperately.
DETAILS & PLAY
SCAN
• Rapid ram advance mechanism • Right or Left handed operation
www.specialisedforce.com.au
• Well balanced design • Quality backed by ISO9001
• 14.4 VDC powerful motor
• Simple spring loaded twist pin design for changing head
ORDERING INFORMATION
SL-CH SL-ACSR SL-GW
SL-ND SL-6CJ BP-80Li CH-100 6T-6mm SL-CB
Model No. Description Tool Crimp AL/CU ACSR AL/CU/ACSR Lith-ion 12-230V Rounding Bending
Only Head Cutting Cutting Cutting Battery Charger Die Tool
Head Head Head
SL-ND 6T Tool Only 1
6T Tool with
SL-ND(BB) Lithium-ion Battery 1 2 1
& Charger
SL-ND/6CJ(BB) 6T Crimping Tool 1 1 2 1
6T AL/CU
SL-ND/CH(BB 1 1 2 1
Cutting Tool
6T Crimping &
SL-ND/6CJ/ACSR(BB) 1 1 1 2 1
ACSR Cutting Tool
6T ACSR
SL-ND/ACSR(BB) 1 1 2 1
Cutting Tool
6T AL/CU/ACSR
SL-ND/GW(BB) 1 1 2 1
Cutting Tool
SL-ND
FENCING TOOL 6T Fencing Tool 1 1 2 1 1
6T Cable
SL-ND/CB(BB) 1 2 1 1
Bending Tool
NOTE: All Tool Combinations Supplied with Case. Contact your Nearest Specialised Force Branch to Design your Own Kit.
Refer to Page/s: 10-11 for Battery & Charger Details; 27 for 6T Crimping Dies & 374 for Bending Head Details
