PUNCH KITS – HAND
HYDRAULIC

HYDRAULIC PUNCH KIT (MADE IN USA)

• Fast, easy and simple to operate.
• Compact design for field use on construction sites and
maintenance jobs.
• Punches 10 times faster than wrench method.
• Can be used with most standard round Slug-BusterR
and Slug-Splitter SC™ punches along with Shark punch
and dies.
J HOLE MAKING & BENDING
• Can be used with non-round punches
(adapter may be required).
• 3-foot hose
• Powerful 11-ton hydraulic ram.

Model No. Description Wt (kg)

15906 Driver, Hand Pump, Draw Studs and 10.9
Spacers and Plastic Case

RAM AND HAND PUMP HYDRAULIC DRIVER
PARTS IDENTIFICATION
Model No. Item # Description
17091 A Ram (includes Item B)
10109 B Draw Stud–3/4” x 135mm
03170 F Punch Sleeve
20963 G Draw Stud–3/8” x 76mm

15908 H Spacer Group (includes Items I, J Example of kit only
and K)
03248 I Spacer-Short (Punch and dies not included)
03249 J Spacer-Medium
06904 K Spacer-Long
34410 L Kwik StepperR Step Bit 1/2”
13284 M Hydraulic Hand Pump
www.specialisedforce.com.au
06302 N High Pressure Hose–1/4” x 3’
30206 R Plastic Case PROUDLY MARKETED, SERVICED
& SUPPORTED AUSTRALIA WIDE

MORE PUNCH & DIES FROM PAGE 346
