TAPES – NYLON FISHING
& LEADERS

NYLON FISH TAPE & LEADER

FEATURES
• Co-extruded curl-resistant nylon fish tape fishes equally well in large and
small conduit.
• High-impact nylon, one-piece handle for maximum durability, long life, and
easy, comfortable use.
• Heavy-duty winder case.
• Nylon fish tape is intended for fishing only. Rope or line is recommended for
pulling.
SPECIFICATIONS

Tape Size 4.8mm ø
Tensile Strength (kN) 1.1

Model No. Description
12715 15.2 m × 4.8 mm diameter Nylon Fish Tape in 300 mm OD E UNDERGROUND PULLING
Winder Case
30.5 m × 4.8 mm diameter Nylon Fish Tape in 300 mm OD
12716
Winder Case
12483 15.2 m × 4.8 mm diameter Nylon Fish Tape without Winder Case
12484 30.5 m × 4.8 mm diameter Nylon Fish Tape without Winder Case
01664 Tip (Requires hex crimp to install.)

FLEX-O-TWIST FLEXIBLE FISH TAPE LEADER

• Helps guide 3.2 mm steel tapes through sharp bends.
• Thread on the end of the fish tape in place of the swivel ball head.

Model No. Description Specifications
30859 305 mm Flexible Fish Tape Leader Weight 0.6 kg

SPEEDFLEX FLEXIBLE FISH TAPE LEADER
• Silver-solder joint attaches to any 3.2 mm x 1.5 mm steel fish tape to
provide a slim profile that fishes farther, faster.
• High-strength stainless steel cable is used for reliability and long life.
• Bevelled edges on the leader reduce the possibility of hang-ups when
pulling wire.
• Several wires can be attached to the large pulling eye.

Model No. Description Specifications www.specialisedforce.com.au
14392 305 mm SPEED FLEX Leader (solder joint) Weight 0.6 kg

Refer page 182 & 183 for Steel Fish Tape
