CABLE DRUM HANDLING –
LEVER & STANDS

Australian made Cable Drum Handling equipment to accommodate all sizes and types of
Drums, for workshop and worksite operation.
Australian Made
CABLE DRUM LEVER Model No. DL-150

• Lightweight and transportable
• Cable Drum Frame utilises a leverage of approximately
6:1 to aid with the lifting
• Lifts drums up to 1500mm OD x 1000mm wide
• Includes a 50mm Axle and two retaining collars
• Ideal for factory or workshop environment

Dimensions Max Drum Max Drum WLL Weight
Model No. Description
(mm) Diameter mm Width mm Kg kg
DL-150 CABLE DRUM 1780 x 1260 x 1400 970 150 25
LEVER 830 (LxWxH)
ROPE STAND Model No. CRS-290
• Lightweight and transportable
• Folds flat for storage and transport E UNDERGROUND PULLING
• Useable axle length 800mm
• Used in Industrial situation with powder coated finish
• Includes zinc plated axle 33mm OD

Dimensions Drum Width mm Weight
Model No. Description
(mm) Min Max kg
CABLE REEL 1780 x 1260 x SMALL BUILDERS
CRS-290 5.8
STAND 830 (LxWxH) CABLE DRUMS*
*Maximum 700mm 50Kg WLL
Dimensions (mm) 900 x 531 x 400 (LxWxH)
Folded Dimensions (mm) 900 x 531 x 140 (LxWxH)
ROPE CADDY Model No. CRC-600
• Lightweight and transportable
• Suitable for Workshop & Worksite applications
• Axle 90mm OD
• Complete with drum seated on grease able bearings, crank handle and two
pneumatic wheels for mobility over rugged terrain
• Frame is powder coated, barrel zinc plated finish
• Manufactured with mandrel bent pipe work for maximum strength

Max Drum
Model No. Description Weight kg
Width mm
CRC-600 CABLE DRUM CADDY 500 30 www.specialisedforce.com.au

Dimensions (mm) 800 x 930 x 1090 (LxWxH)
2,100m of 6mm rope, 1,300m of 8mm rope,
Capacity 550m of 12mm rope, 320m of 16mm rope
CRC-600
ROPE STAND Model No. RS-2419

• Axle 50mm OD
• Simple but very rigid stand to suit drums of rope or cabling. C/W washer and snap
lock pin to retain drums. Black powder coated finish

Dimensions Max Drum Max Drum OD RS-2419
Model No. Description Weight kg
(mm) Width mm mm 60Kg WLL
590 x 500 x
RS-2419 ROPE STAND 366 (LxWxH) 480 600 11.8
