WINCH – TIRFOR HYDRAULIC

TUH SERIES SUPERTIRFOR HYDRAULIC TIRFOR WINCH

The Tractel TUH Series Hydraulic Tirfor® machines are portable
motorised hoists used with maxiflex wire rope.

TU 16 H TU 32 H

FEATURES
• Can be used to lift, pull and position loads over great
distances depending on the wire rope length.
• Suitable for use in numerous configurations and are the ideal
solution for use in professional applications.
• Operated by a hydraulic cylinder powered by either an
electrical power pack or a petrol motor power pack. D WINCHES

NOTE: The load capacity of the Tirfor system can be increased
®
by using sheave blocks.

• Multiple machines can be operated by a single operator.
• Systems can be operated at a distance.
• No operator fatigue.

CAPACITY
By using the sheave block technique, the capacity of the
Hydraulic Tirfor can be increased by a factor of 2, 3, 4 or
®
more.
• They can be used to lift, pull and position loads over great
distances depending on the wire rope length.
• This special mechanism maintains a constant lifting or pulling
capacity.
CONFIGURATIONS

The Hydraulic Tirfor can be used in various configurations, up to 4 hoists at the same time.
®
Forward Operation Reverse Operation (m/ www.specialisedforce.com.au
(m/min) min) Hydraulic Power Pack

Rope
Model Capacity Length Height Thickness
No. (kg) (mm) (mm) (mm) (mm Dimensions
OD) Conf1 Conf2 Conf3 Conf1 Conf2 Conf3 1 way(kg) 2 way(kg) 3 way(kg) Pack (mm)
of Power

TU 16 H 1600 788 360 185 11.5 2 1.5 0.75 2.3 2 1 43.5 44.1 45.1 460 x 550 x
500
460 x 550 x
TU 32 H 3200 1070 430 204 16.5 0.7 0.35 0.17 1.6 0.8 0.4 43.5 44.1 45.1
500
NOTE: Special Pumps are Required to Operate – Contact Specialised Force for More Information.
