P. 424
REFERENCE TABLES
HV XLPE INSULATED NON METALLIC SCREENED ABC 6.35/11 & 12.7/22KV XLPE
INSULATED NON METALLIC SCREENED AERIAL BUNDLED CABLES TO AS/NZS 3599.2.
ALUMINIUM CONDUCTORS, ALUMINIUM ALLOY 1120 SUPPORT CONDUCTOR.
Nominal Average Minimum Bending
Nominal Average Nominal AAAC/1120 Support Nominal
Nominal Conductor Insulation Diameter Insulation Diameter Conductor Overall Approx. Radius - Installed
Conductor Diameter Thickness Over Screen Over Core Diameter Mass (mm)
Area (mm2) Insulation Thickness Size Diameter (kg/km)
(mm) (mm) (mm) (mm) Core Cable
(mm) (mm) (No./mm) (mm)
6.35/11kV
35 6.9 3.4 14.9 1 17.1 7/4.75 14.3 48.4 1170 260 480
50 8.1 3.4 16.0 1 18.2 7/4.75 14.3 50.7 1320 270 510
REFERENCES TABLES
70 9.6 3.4 17.6 1 19.8 7/4.75 14.3 53.9 1560 300 540
95 11.4 3.4 19.3 1 21.5 7/4.75 14.3 57.3 1860 320 570
120 12.8 3.4 20.7 1 22.9 19/3.50 17.5 63.3 2280 340 630
150 14.2 3.4 22.1 1 24.3 19/3.50 17.5 66.2 2570 360 660
185 15.7 3.4 23.6 1 25.8 19/3.50 17.5 69.2 2890 390 690
12.7/22kV
35 6.9 5.5 19.2 1 21.4 7/4.75 14.3 57.1 1540 320 570
50 8.1 5.5 20.3 1 22.5 7/4.75 14.3 59.3 1710 340 590
70 9.6 5.5 21.9 1 24.1 7/4.75 14.3 62.5 1990 360 630
95 11.4 5.5 23.6 1 25.8 7/4.75 14.3 66 2310 390 660
120 12.8 5.5 25.0 1 27.2 19/3.50 17.5 72 2760 410 720
150 14.2 5.5 26.4 1.1 28.8 19/3.50 17.5 75.2 3100 430 750
185 15.7 5.5 27.9 1.1 30.3 19/3.50 17.5 78.2 3460 460 780
Stranding & Cross- Minimum Rec. Tension
Nominal Wire X Nominal Overall sectional Breaking Highest Max. Working
(No./mm) Diameter (mm) Area (mm2) Load (kN) Everyday (kN) (kN)
7/4.75 14.3 124.0 27.1 4.1 13.6
19/3.50 17.5 182.8 41.7 6.3 20.9
HV XLPE INSULATED NON METALLIC ABC HDPE 6.35/11 & 12.7/22KV XLPE
INSULATED NON METALLIC SCREENED AERIAL BUNDLED CABLES WITH HDPE
COVERING TO AS/NZS 3599.2. ALUMINIUM CONDUCTORS, ALUMINIUM ALLOY 1120
SUPPORT CONDUCTOR.
www.specialisedforce.com.au
Nominal Average Minimum
Nominal Average Nominal AAAC/1120 Support Nominal
Nominal Diameter Insulation Conductor Approx. Bending Radius -
Conductor Conductor Insulation Over Screen Diameter Overall Mass (kg/ Installed (mm)
Area (mm2) Diameter Thickness Insulation Thickness Over Core Size Diameter Diameter km)
(mm) (mm) (mm) (mm) Core Cable
(mm) (mm) (No./mm) (mm)
6.35/11kV
35 6.9 3.4 14.9 1.8 18.8 7/4.75 14.3 52.0 1320 280 520
50 8.1 3.4 16.0 1.8 20.0 7/4.75 14.3 54.2 1490 300 540
70 9.6 3.4 17.6 1.8 21.6 7/4.75 14.3 57.4 1740 320 570
95 11.4 3.4 19.3 1.8 23.3 7/4.75 14.3 60.9 2050 350 610
120 12.8 3.4 20.7 1.8 24.7 19/3.50 17.5 66.9 2480 370 670
150 14.2 3.4 22.1 1.8 26.1 19/3.50 17.5 69.7 2780 390 700
185 15.7 3.4 23.6 1.8 27.6 19/3.50 17.5 72.7 3120 410 730
12.7/22kV
35 6.9 5.5 19.2 1.8 23.1 7/4.75 14.3 60.6 1730 350 610
50 8.1 5.5 20.3 1.8 24.3 7/4.75 14.3 62.9 1910 360 630
70 9.6 5.5 21.9 1.8 25.9 7/4.75 14.3 66.1 2200 390 660
95 11.4 5.5 23.6 1.8 27.6 7/4.75 14.3 69.5 2530 410 690
120 12.8 5.5 25.0 1.8 29.0 19/3.50 17.5 75.5 3000 430 750
150 14.2 5.5 26.4 1.8 30.4 19/3.50 17.5 78.3 3320 460 780
185 15.7 5.5 27.9 1.8 31.9 19/3.50 17.5 81.3 3690 480 810
Stranding & Cross- Minimum Rec. Tension
Nominal Wire X Nominal Overall sectional Breaking Highest Max. Working
(No./mm) Diameter (mm) Area (mm2) Load (kN) Everyday (kN) (kN)
7/4.75 14.3 124.0 27.1 4.1 13.6
19/3.50 17.5 182.8 41.7 6.3 20.9
