DYNAMOMETERS –
ELECTRONIC/DIGITAL

LLXH ELECTRONIC / DIGITAL –
DYNAMOMETERS

DYNAFOR™ Offer an extensive range of load
link dynamometers based on the strain gauges
technology. This State-of-the art technology is
utilised in the new generation LLX2 and LLXH,
the connection between sensor and display,
USB connection between display and PC, and
monitoring software.
LLXH-25T shown
The dynafor™ LLXH (h for hybrid) are precision
appliances for measuring pulling force and indicating
loads.

They combine the proven mechanical body of the LLX G DYNAMOMETERS & LOAD CELLS
with the new electronic software from the LLX2.
They are precise within +/- 0.2% and are available from
15T (150kN) to 250T (2,500kN).

SPECIFICATIONS
LLXH LLXH LLXH LLXH LLXH
MODEL Display
15T 25T 50T 100T 250T
Maximum
capacity Tonne 15 25 50 100 250 ALL
Test load Tonne 30 50 100 200 500 - 82mm
Safety coefficient Minimum -
0.2% according to ISO 376 . 21°C -
Precision
daN 30 50 100 200 500 -
Increment daN 5 10 20 50 100 <

Max. display 16500 27500 55000 110.00 275.00 <
daN
daN
t
t
daN
Number height mm - - - - - 25 131mm
27mm
Autonomy From 300 to 1000 h depending of functions 48 h
Radio scope m 80 (in open field) (IP67 = 60)
RF Technology 2.4 Ghz
Weight kg 4 6.6 15.1 46 215 0.180
IP Protection IP 65 (option : IP 67) IP 54 www.specialisedforce.com.au
Usage From - 20° to 40°C
Sensitivity to T° 0.05% per 10°C
Sensor material Aluminium -
A 320 360 440 660 905 -
B 247.5 277 338 488 685 -
Dimensions C 47.5 56 72 108 150 -
(mm) D 130 134 164 260 424 -
E 58 68 98 118 248 -
F 48 58 86 104 190 -
